Morris
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 80.9625 | 44.45 | 22 | 3.149606 | 3 3/16 | 1 3/4 | 0.866142 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
6 cyl piston set 12584 for Chrysler, Plymouth - 6 Cyl, CI, CM, CD, De Luxe, CP 8Cyl, CO 6Cyl, 33.8h.p. Heston, Kingston, Airflow 8, Airflow Imperial 8, Airflow Custom, Imperial 8, Airstream 8,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 93.6625 | 50.8 | 21.828125 | 3 1/4 | 3 11/16 | 2 | 55/64 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
4 cyl piston set 2326 for Ford - 14.9h.p. AF, ABF, C.R. 5.2 to 1, Aluminium version of 2481
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.597 | 89.69375 | 48.41875 | 25.4 | 3.055 | 3 17/32 | 1 29/32 | 1 |
6 cyl piston set 3382 for Jaguar - 20h.p. 2663cc SSI
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 79.375 | 39.6875 | 15.875 | 2 7/8 | 3 1/8 | 1 9/16 | 5/8 |
1 cyl piston set 4635 for Villiers - 98cc Midget, Gudgeon pin parallel to deflector, Two-Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 50 | 71.4375 | 39.6875 | 12.5 | 1.968504 | 2 13/16 | 1 9/16 | 0.492126 |
6 cyl piston set 4830 for Humber - 16.95h.p. 2276cc
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.5 | 97.75 | 48 | 20 | 2.65748 | 3.848425 | 1.889764 | 0.787402 |
4 cyl piston set 5430 for Humber - 12h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 2.73622 | 0 | 0 | 0 | |||
4 cyl piston set 5814 for Jowett - 10h.p. J, 7J, 8J, 9J, 10J, Flat Four C.R. 5.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 76.2 | 44.45 | 19.05 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 3/4 | 3/4 |
6 cyl piston set 7382 for Commer - 20.9h.p. N2, N3, N4, PN3, Q2, Q3, Superpoise, 30, 40, 60cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
1 cyl piston set 7494 for Cletrac Tractor - BD Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 123.03125 | 76.99375 | 30.1625 | 3 3/4 | 4 27/32 | 3 1/32 | 1 3/16 |
4 cyl piston set 7664 for Austin - 11.9h.p. 1535cc 12/4 C.R 6.2 to 1 4 cyl 1933-47, 17.9h.p. 2510cc fitted to 16h.p. chassis C.R 6.3 to 1, 6 cyl, Light 12/4, 8/10cwt 4cyl, 15cwt, Ambulance 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.342 | 79.375 | 38.1 | 15.875 | 2.73 | 3 1/8 | 1 1/2 | 5/8 |
6 cyl piston set 7672 for Austin - 13.9h.p. 1496cc Twelve Six, 12h/p/ 10cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.214 | 63.5 | 33.3375 | 14.2875 | 2.41 | 2 1/2 | 1 5/16 | 9/16 |
4 cyl piston set 7687 for Ford - 8h.p. Model Y, 5cwt, Tug, 40cwt, ring below pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.642 | 61.11875 | 26.19375 | 17.4625 | 2.23 | 2 13/32 | 1 1/32 | 11/16 |
4 cyl piston set 7695 for Hillman - 9.8h.p. 1185cc Minx, Minx Magnificent, Aero Minx
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 76.99375 | 38.89375 | 16 | 2.480315 | 3 1/32 | 1 17/32 | 0.629921 |
4 cyl piston set 7765 for Morris - 10h.p. 1292cc Ten Four Series II, III
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74 | 37.5 | 16 | 2 1/2 | 2.913386 | 1.476378 | 0.629921 |
6 cyl piston set 7787 for Austin - 16h.p. Export
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 76.2 | 38.1 | 15.875 | 2.57874 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
6 cyl piston set 7804 for Morris - 16h.p. 2062cc Oxford
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 77 | 40.5 | 18 | 2.57874 | 3.031496 | 1.594488 | 0.708661 |
4 cyl piston set 7808 for Standard - 12h.p. 1608cc, C.R. 5.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 78.978125 | 39.290625 | 15.875 | 2.73622 | 3 7/64 | 1 35/64 | 5/8 |
4 cyl piston set 7819 for Rover - 10.8h.p. 21389cc Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.5 | 40.084375 | 78.184375 | 15.875 | 2.61811 | 1 37/64 | 3 5/64 | 5/8 |
4 cyl piston set 7984 for Standard - 10h.p. 1267cc Flying Ten C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.025 | 38.1 | 19.05 | 2 1/2 | 2 7/8 | 1 1/2 | 3/4 |
6 cyl piston set 8107 for Commer - 20/70h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 2.952756 | 0 | 0 | 0 | |||
4 cyl piston set 8112 for Standard - 8h.p. 1021cc, Flying Eight C.R 6.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57 | 73.025 | 38.1 | 15.875 | 2.244094 | 2 7/8 | 1 1/2 | 5/8 |
6 cyl piston set 8282 for Vauxhall - 14h.p. 1781cc, J, C.R 6.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 2.42126 | 0 | 0 | 0 | |||
1 cyl piston set 8499 for Armstrong Siddeley - 14h.p. 1668cc
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.96 | 76 | 41 | 15.875 | 2.4 | 2.992126 | 1.614173 | 5/8 |
1 cyl piston set 8684 for Bedford - 20h.p. BYC, 12cwts C.R. 5.625 to 1. Aluminium Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 77.7875 | 41.275 | 22.225 | 2 7/8 | 3 1/16 | 1 5/8 | 7/8 |
6 cyl piston set 8735 for Lanchester - 14.06h.p. 1809 cc Fourteen, Roadrider De Luxe, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.468 | 80.16875 | 44.45 | 17.77 | 2.42 | 3 5/32 | 1 3/4 | 0.699606 |
4 cyl piston set 8788 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston, ring below pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
6 cyl piston set 8829 for Morris - Oxford S II, 2062cc, 16h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 80.5 | 42.5 | 18 | 2.57874 | 3.169291 | 1.673228 | 0.708661 |
6 cyl piston set 8967 for REO - IA4H, IA4HY, IB4 (After Eng 14000), H/M/Y, IB7M/MY, IC4H/HY, ID4, H/Y, IL5H, 2B, 4/4R/7M, 2D, 4/4M/4MH/4DR, 2H, R/5/5Z, 2J, R/5Z, 2K/2KR, 2L, M/4/4C/7M/7MF, DFX,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 101.996875 | 82.153125 | 25.003125 | 3 3/8 | 4 1/64 | 3 15/64 | 63/64 |
1 cyl piston set 9001 for Renault - 8.3h.p.SV, 1003 cc Juva RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 58 | 65.5 | 32.5 | 15 | 2.283465 | 2.57874 | 1.279528 | 0.590551 |
4 cyl piston set 9178 for Lanchester - 10h.p. 1203 cc Car Nos 15000 to 20050
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.05625 | 38.1 | 15.875 | 2 1/2 | 2 23/32 | 1 1/2 | 5/8 |
6 cyl piston set 9301 for Austin - 28.3h.p. 6 wheeler 4-wheel drive, twin rear axle K3/YF, 4-wheel drive K3/ZD, K5. Cast Iron piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 93.6625 | 47.625 | 22.225 | 3 7/16 | 3 11/16 | 1 7/8 | 7/8 |
1 cyl piston set 9655 for John Deere - B, BI, BN, BW, BO, BR, Horizontal
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 114.3 | 142.875 | 82.55 | 31.242 | 4 1/2 | 5 5/8 | 3 1/4 | 1.23 |
1 cyl piston set 9748 for Douglas - 540cc SV Industrial Air Cooled
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 84.1375 | 47.625 | 22.225 | 3 1/4 | 3 5/16 | 1 7/8 | 7/8 |
1 cyl piston set 10014 for Humber - 4 cyl 12h.p. 1669cc, 6 cyl 17.97h.p. 2731cc Snipe
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 92.67 | 51 | 22 | 2.73622 | 3.648425 | 2.007874 | 0.866142 |
4 cyl piston set 10157 for Austin - 10h.p. Ten Four, 1125cc
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
4 cyl piston set 10345 for Perkins - PA, PB, P4, 4192, 14.7h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9254 | 3.501 | 0 | 0 | 0 | |||
4 cyl piston set 10520 for Lanchester - 10h.p. 1203 cc Car 20051 Upwards, 1287 cc OHV Ten LD10, CR 7.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.025 | 38.1 | 17.77 | 2 1/2 | 2 7/8 | 1 1/2 | 0.699606 |
4 cyl piston set 10931 for Hillman - 1265 cc Minx Mark IV, V, VI, VII, SV, Husky, MkI, CR 6.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.0875 | 73.92 | 39 | 17.4625 | 2 9/16 | 2.910236 | 1.535433 | 11/16 |
6 cyl piston set 11209 for Studebaker - 21.6h.p. 2708 cc SV Champion G
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 73.81875 | 40.48125 | 19.0373 | 3 8.8817841970013E-16/2 | 2 29/32 | 1 19/32 | 0.7495 |
4 cyl piston set 11581 for Morris - 6 cyl 14.9h.p. Major QX, Oxford, Fifteen Six. 4 Cyl Ten Four
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
1 cyl piston set 12064 for AEC - A312, 5.123 Lit. 4Cyl. 1685cc. AV470/AH470/Regent MkV/Reliance/Mercury/8 ton/7.75 Lit, 6 Cyl, Direct injection Diesel, C.R. 16 to 1 - RBP, H'lex Tin Plated
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 112 | 152.2476 | 91.9226 | 40 | 4.409449 | 5.994 | 3.619 | 1.574803 |
6 cyl piston set 12545 for Morris - 14h.p. 1818 cc Morris Series II and III, Fourteen Six, 'Q'
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 70 | 42.5 | 18 | 2.42126 | 2.755906 | 1.673228 | 0.708661 |
6 cyl piston set 12768 for Austin - 4 cyl 2660 cc OHV Champ, 5 cwt. 6 cyl 3993 cc OHV 4 Litre , Loadstar, 2-5 ton/ 4x4 1 ton, 6 cyl.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
4 cyl piston set 13556 for Austin - 948 cc O.H.V. A35, A40 Healey Sprite, Low Comp CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 14370 for Standard - 1009 cc SV Flying Eight, CR 6.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.7 | 73.025 | 38.1 | 15.875 | 2.232283 | 2 7/8 | 1 1/2 | 5/8 |
4 cyl piston set 15707 for Fiat - 767 cc OHV 600D, CR 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62 | 62 | 31 | 20 | 2.440945 | 2.440945 | 1.220472 | 0.787402 |
1 cyl piston set 16216 for Austin - 1622 cc OHV A60, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.1873 | 76.99375 | 42.06875 | 19.05 | 2.9995 | 3 1/32 | 1 21/32 | 3/4 |
4 cyl piston set 16422 for Volkswagen - 1493 cc OHV 1500S, RWD Air Cooled, 341 motor CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 88 | 45 | 22 | 3.267717 | 3.464567 | 1.771654 | 0.866142 |
4 cyl piston set 17215 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7494 | 75.565 | 37.6174 | 3.061 | 2.975 | 1.481 | ||
4 cyl piston set 17363 for Audi - 1696 cc O.H.V. Audi 80/F103, 1700s-103 Engine. CR 11 to 1, SSD
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 72.5 | 43.5 | 24 | 3.149606 | 2.854331 | 1.712598 | 0.944882 |
4 cyl piston set 17560 for Ford - 1298 cc OHV Escort 1300GT, Capri 1300 GT, 2735E Engine, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 17916 for Triumph - 1964 1998 cc OHV 2000, CR 8.5 to 1. 1965/70 OHV 2000, CR 9 to 1. 1968 OHV 2000 PI, CR 9.5 to 1. 1967/1970 OHV Vitesse GT6, 2 Litre CR 9.5 to 1. 1968/70,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74.6887 | 74.1426 | 38.1 | 20.6375 | 2.9405 | 2.919 | 1 1/2 | 13/16 |
4 cyl piston set 18495 for Hillman - 1248 cc OHV Avenger, De Luxe, Super, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.6003 | 75.803125 | 44.053125 | 23.8125 | 3.0945 | 2 63/64 | 1 47/64 | 15/16 |
4 cyl piston set 18643 for Ford - 940 cc OHV Export Escort 940, CR 9.5 to 1, Uprated 711M Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18683 for Ford - 1298 cc OHV Escort 1300GT, Capri 1300 GT, 2735E Engine, CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18802 for Austin - 1798 cc OHV 1800, 1800 HL, 1800 MkII/MkIII CR 9 to 1, 1800S MkII CR 9.5 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.23733 | 61.1124 | 42.164 | 20.6375 | 3.15895 | 2.406 | 1.66 | 13/16 |
2 cyl piston set 19131 for Ford - 1969-71 1996 cc OHV Capri 2000GT, V4, CR 8.9 to 1. 1972 onwards 2994 cc OHV Capri, Consul GT, Granada, Granada GXL, 3 litre V6, CR 8.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 95.25 | 46.1391 | 23.8125 | 3.6869 | 3 3/4 | 1.8165 | 15/16 |
4 cyl piston set 19298 for Ford - 5 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
Mini Cooper
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.612 | 58.6105 | 38.0365 | 20.6375 | 2.78 | 2.3075 | 1.4975 | 13/16 |
4 cyl piston set 19657 for Toyota - 1591 cc 7R Engine, Corona Mk II, 1600 DX. 1707 cc 6R Engine, Corona Mk II, Van DX MkII for LPG. 1858 cc 8R Engine, Corona MkII, Hard Top 1900 GL, 8R-C
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86 | 84.75 | 39.75 | 22 | 3.385827 | 3.336614 | 1.564961 | 0.866142 |
4 cyl piston set 19743 for Mitsubishi - 1439 cc 4G33 Engine, OHC 1400 Colt, Lancer, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 69.7 | 32.7 | 19 | 2.874016 | 2.744094 | 1.287402 | 0.748031 |
2 cyl piston set 19938 for Honda - 249 cc OHC CB250, CB250K2, CB250K3, CB250K4, CB250G5, CR 9.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 62.5 | 32.1 | 15 | 2.204724 | 2.46063 | 1.26378 | 0.590551 |
4 cyl piston set 20139 for Triumph - 1493 cc OHV 1500, CR 8.5 to 1. OHV 1500, 1500TC, Spitfire 1500, Dolomite 1500, 1500HL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.6473 | 58.0898 | 32.6898 | 20.6375 | 2.8995 | 2.287 | 1.287 | 13/16 |
4 cyl piston set 20228 for Datsun - 1288 cc B210 A13 Engine.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 67.5 | 32.6 | 17.452 | 2.874016 | 2.65748 | 1.283465 | 0.687087 |
1 cyl piston set 20350 for Suzuki - 2 Cyl 398 cc DOHC GS400, GS400C, GS400EC, GS400N, GS400EN. 4 Cyl 750 cc DOHC GS750, C/DC/N/DN
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65 | 63.7 | 35.8 | 16 | 2.559055 | 2.507874 | 1.409449 | 0.629921 |
4 cyl piston set 20398 for Austin, Morris - 1098 cc 'A' Series Engine OHV 1100/Minor 1000/ 6 cwt Van/Marina 7 cwt Van, Low Comp CR 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.0517 | 30.3276 | 15.875 | 2.542 | 2.2855 | 1.194 | 5/8 |
4 cyl piston set 20548 for Ford - 1098 cc OHV Escort 6-8 cwt Van, Escorty 1100, Popular 1100, 751M Engine High Comp, CR 9 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20614 for Volvo - 4 Cyl, 1986 cc B20A, B20F Engines, OHV, 142, 142E, 144, 144 E, 145, 142 S, 144 S, 145 S, 144 DL, 145 DL, 144 GL, 1800 E, 1800 S, 1800 ES, CR 8.7 to 1. B20B...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.89 | 71 | 46.1 | 22 | 3.499606 | 2.795276 | 1.814961 | 0.866142 |
4 cyl piston set 20747 for Mini - 1275 cc OHV Cooper S, CR 9.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.612 | 58.6105 | 38.0365 | 20.6375 | 2.78 | 2.3075 | 1.4975 | 13/16 |
4 cyl piston set 20950 for Austin, Mini, Morris - 998 cc A Series Mini Cooper, CR 8.4/9.1 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 60.72124 | 33.8582 | 15.875 | 2.542 | 2.3906 | 1.333 | 5/8 |
4 cyl piston set 21075 for Austin - 1695 cc 'O' Series OHC Ambassador 1.7L/HL, Princess 1700L/HL/HLS, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.4423 | 73.37044 | 43.41876 | 20.64258 | 3.3245 | 2.8886 | 1.7094 | 0.8127 |
4 cyl piston set 21145 for Honda - 498 cc XL500, S/SZ/Z/A
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 89 | 65.2 | 29.2 | 21 | 3.503937 | 2.566929 | 1.149606 | 0.826772 |
4 cyl piston set 21262 for Vauxhall - 1598 cc 1.6N, 1.6S Engine, OHC Astra 1600L, GL, SR, Belmont 1600L, GL, GLS, Cavalier, L, GL, LX, SR, GLS. CR 9.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 72 | 40.05 | 23 | 3.149606 | 2.834646 | 1.576772 | 0.905512 |
4 cyl piston set 21813 for Nissan - 1595 cc L16 Engine. 1967-73; Bluebird 1600. 73-80; (P510). 73-80; Bluebird 160B (610, L610, LJ810, V610, VLJ810). 80-84; Bluebird 1.6 GL (TJ910, TLJ910)....
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83 | 78 | 38.1 | 21 | 3.267717 | 3.070866 | 1 1/2 | 0.826772 |
4 cyl piston set 22304 for Opel - 1598 cc X1.6SZ Engine, Single Point Injection, Astra GL/GLS/CDX/Season/Club, CR 10.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79 | 48 | 28.05 | 18 | 3.110236 | 1.889764 | 1.104331 | 0.708661 |
6 cyl piston set 164505 for Leyland - 5.76 Litre, 0350 Mk II, Comet 90, Comet 100, Tiger Club, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.62718 | 132.715 | 81.915 | 33.02 | 3.9617 | 5.225 | 3.225 | 1.3 |
1 cyl piston set 231414 for Leyland - 6.17 Litre, 0375, Super Comet, Direct Injection Diesel, CR 16 to 1, Al Fin design parallel rings
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 104.18318 | 132.7531 | 81.9531 | 33.02 | 4.1017 | 5.2265 | 3.2265 | 1.3 |
1 cyl piston set 350026 for Petter - PAZI, Air Cooled, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 92 | 55.042 | 27 | 3 8.8817841970013E-16/2 | 3.622047 | 2.167008 | 1.062992 |
1 cyl piston set 350067 for Ford - 4D 240 cubic inches, D Series, 2701E Vertical, 2706E Inclined. 6D 360 cubic inches, D Series 2704E Vertical, 2709E Inclined. Diesel, CR 16.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 104.775 | 118.11 | 71.0311 | 34.925 | 4 1/8 | 4.65 | 2.7965 | 1 3/8 |
1 cyl piston set 350188 for David Brown - DB1410, DB1412, AD 4/55 Engines, Turbocharged, Diesel, CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
6 cyl piston set 350227 for Ford - 6571 cc 401 Cu. In, 6 cyl Dexta Tractor, Series 6Y, 8000, Series 7A, 8600, 8700. CR 16 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 106.69778 | 126.9746 | 68.1228 | 38.1 | 4.2007 | 4.999 | 2.682 | 1 1/2 |
1 cyl piston set 350277 for Leyland - 4 Cyl, 3.77 Litre Leyland 4/98 Series, 6 cyl, 5.65 Litre, 6/98 Series, Turbocharged Diesel, Al Fin Design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98 | 116.307 | 68.25 | 36.5125 | 3.858268 | 4.579016 | 2.687008 | 1 7/16 |
4 cyl piston set 350318 for Opel - 2068 cc 2.1D Engine, Blitz 2.1D, Rekord 2.1D, L, Berlina, Caravan, CR 21/22/24 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 88.75 | 53.8 | 28 | 3.464567 | 3.494094 | 2.11811 | 1.102362 |
2 cyl piston set 350385 for Bedford - 8200 cc 500 phase 1 engine. Direct injection TM Series 7400000 -> Al fin design for 350262
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 115.8875 | 122.4788 | 75.82916 | 44.45 | 4 9/16 | 4.822 | 2.9854 | 1 3/4 |
4 cyl piston set 350449 for Mazda - 2184 cc R2 Engine, E2200 Van, Pick-Up, Crew Cab. CR 22.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86 | 86.25 | 47.25 | 25 | 3.385827 | 3.395669 | 1.860236 | 0.984252 |
4 cyl piston set 403801 for Alfa Romeo - 1186 cc 301.00 Engine, Alfasud L, N, SM, Super 1.2, Arna 1.2. CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 74 | 39 | 21 | 3.149606 | 2.913386 | 1.535433 | 0.826772 |
1 cyl piston set 483506 for Lister - SR Series, Air Cooled Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 103.1875 | 65.0875 | 29.36875 | 3 1/2 | 4 1/16 | 2 9/16 | 1 5/32 |
1 cyl piston set 586006 for David Brown - 3 cyl 2395 cc 770, 4cyl 3195 cc 990, Direct Injection Diesel, CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 111.9124 | 66.7258 | 31.75 | 3.9388 | 4.406 | 2.627 | 1 1/4 |
6 cyl piston set 664098 for Fiat - 2054 cc OHV 2100 Engine type 114, C.R 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 85.75 | 48.5 | 22 | 3.031496 | 3.375984 | 1.909449 | 0.866142 |
4 cyl piston set 666169 for Alfa Romeo - 1186 cc O.H.C. Alfasud up to Engine 79081. CR 8.75 to 1. Steel Strut design, Piston Pin press fit into con-rod
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 71.65 | 36.65 | 21 | 3.149606 | 2.820866 | 1.442913 | 0.826772 |
6 cyl piston set 667193 for Fiat - 1116 cc 128.A.000, 128.AC5000, 138.AE.0190 Engines, OHC 128 Sport Coupe, Sport Coupe L, Ritmo 60, Strada 60 128 Special, 128-3P
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 74.8 | 35.3 | 22 | 3.149606 | 2.944882 | 1.389764 | 0.866142 |
4 cyl piston set 667689 for Fiat - 1995 cc 132 C3.000. Jetronic Fuel Injection, Argenta 2000i, 132/2000i
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84 | 77.95 | 38.45 | 3.307087 | 3.068898 | 1.51378 | ||
4 cyl piston set 789110 for Renault - 1969-71 1289 cc OHV R10 1300 CR 8 to 1. 1970 On, 1289 cc OHV R12L, R12TL, R12TR, R12TS, R15TL, R5LS, R5TS, CR 9.5 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 62.7 | 37.7 | 20 | 2.874016 | 2.468504 | 1.484252 | 0.787402 |
4 cyl piston set 036110 for Simca - 1290 cc OHV 1301S, 1301LS, 1301GL, CR 9 to 1, 1301GLS, CR 9.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 90.3 | 52 | 22 | 2.913386 | 3.555118 | 2.047244 | 0.866142 |
4 cyl piston set 129.14.07 for Peugeot - 2304 cc XD2-XD2P-XD94 Engines, 504 GLD/Berline/Familiale, 505 GRD/SRD, J7 PX/PY/PZ, J9, CR 22.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 94 | 99.9 | 57.42 | 28 | 3.700787 | 3.933071 | 2.26063 | 1.102362 |
6 cyl piston set 19188 JP for Rover - 2995 cc 3 litre, Mk I, II and III, CR 8.75 to 1. 2625 cc 100, 2.6 litre CR 7.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.8 | 98.0186 | 66.3702 | 22.225 | 3.062992 | 3.859 | 2.613 | 7/8 |
