1 cyl piston set 12587 for Austin - 8.3h.p. 803cc O.H.V. A30/Seven, CR 7.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57.912 | 65.0875 | 33.3375 | 14.2875 | 2.28 | 2 9/16 | 1 5/16 | 9/16 |
TR4 (86mm std bore) +.020
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.98916 | 87.3125 | 50.8 | 22.225 | 3.3854 | 3 7/16 | 2 | 7/8 |
1 cyl piston 18796 for Triumph - 1854 cc OHC Dolomite, Dolomite 1850HL, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.987 | 70 | 34.1 | 3.424685 | 2.755906 | 1.34252 |
6 cyl piston set 2727 for Gardner - 36.5h.p. 70/90cwt 6JO ring below pin. Also Gilford
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
98.425 | 111.125 | 60.325 | 28.575 | 3 7/8 | 4 3/8 | 2 3/8 | 1 1/8 |
4 cyl piston set 4674 for Ford - 10h.p.(Short) 1172cc SV Deluxe, C.E. Prefect,
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 65.0875 | 26.19375 | 17.4625 | 2 1/2 | 2 9/16 | 1 1/32 | 11/16 |
6 cyl piston set 5591 for Lanchester - 12h.p. 1378cc Light 6, Sports Saloon, Model 342, Light 6 De Luxe saloon, Model 351
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57 | 69.85 | 31.75 | 15.24 | 2.244094 | 2 3/4 | 1 1/4 | 0.6 |
6 cyl piston set 7393 for Morris - 25h.p. Overseas C.R 5.75 to 1, C.I
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82 | 99 | 55 | 22 | 3.228346 | 3.897638 | 2.165354 | 0.866142 |
4 cyl piston set 7668 for Rover - 11.9h.p. 1496cc Twelve
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69 | 78.184375 | 40.084375 | 15.875 | 2.716535 | 3 5/64 | 1 37/64 | 5/8 |
4 cyl piston set 7691 for Ford - 8h.p. Model Y, 5cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.642 | 59.53125 | 24.60625 | 14.2875 | 2.23 | 2 11/32 | 31/32 | 9/16 |
4 cyl piston set 7771 for Standard - 9.h.p 1052cc, Little 9, 4 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
60.325 | 69.85 | 34.925 | 15.875 | 2 3/8 | 2 3/4 | 1 3/8 | 5/8 |
6 cyl piston set 7806 for Vauxhall - 14h.p. 1781cc Light Six ASX
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61.5 | 75.40625 | 39.6875 | 19.05 | 2.42126 | 2 31/32 | 1 9/16 | 3/4 |
1 cyl piston set 7876 for Morris - 25h.p. 3485cc Series II & III 'O'
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82 | 96 | 51 | 22 | 3.228346 | 3.779528 | 2.007874 | 0.866142 |
6 cyl piston set 8109 for Hillman - 16h.p. 2576cc Sixteen
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
67.5 | 93.5 | 51 | 22 | 2.65748 | 3.681102 | 2.007874 | 0.866142 |
4 cyl piston set 8480 for Austin -
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.769 | 2.235 | 0 | 0 | 0 |
4 cyl piston set 8712 for Hillman - 14h.p. 14/6, 1944cc SV, ring below pin
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 92.25 | 51 | 24 | 2.952756 | 3.63189 | 2.007874 | 0.944882 |
1 cyl piston set 8817 for Buick - 30.6h.p. 34-40, 34-60, 35-40, 35-60, 37-40 Aluminium version of Cast Iron Piston 4699, 8 cylinder
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
78.58125 | 96.8375 | 57.15 | 20.6375 | 3 3/32 | 3 13/16 | 2 1/4 | 13/16 |
4 cyl piston set 8984 for Ford - 8h.p. 933cc Popular Y, short 3 ring piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.642 | 60.325 | 26.19375 | 17.4625 | 2.23 | 2 3/8 | 1 1/32 | 11/16 |
6 cyl piston set 9025 for Humber - 23.8h.p. Snipe, Pullman
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 92.25 | 51 | 24 | 3.149606 | 3.63189 | 2.007874 | 0.944882 |
6 cyl piston set 9185 for Chevrolet - 29.4h.p. GB, GC, GD, GE, HB, HC, HD, HE, JB, JC, JD, JE, KC, KD, KE, S, T, V, W, SA, SB, SC, SD, TA, TB, TC, TD, 2TS, 3TS, 2TL, 3TC, HFC, 1/2 to 1 1/2 ton....
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.9 | 103.1875 | 74.6125 | 21.9583 | 3 1/2 | 4 1/16 | 2 15/16 | 0.8645 |
6 cyl piston set 9309 for Austin - 26.88h.p. 3459cc CX13, 1 1/2 to 5 ton, 20-26 seater passenger bus C.R. 5.75 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 9744 for Dodge - 23.4h.p. Aluminum version of piston 4983
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.375 | 93.6625 | 50.8 | 21.828125 | 3 1/8 | 3 11/16 | 2 | 55/64 |
4 cyl piston set 9825 for Renault - 13.9h.p. KZ3-8, 4 Cyl, Aluminium version.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 91.5 | 51 | 18 | 2.952756 | 3.602362 | 2.007874 | 0.708661 |
6 cyl piston set 10083 for Chrysler - 28.35h.p. 4100cc, SV, C34, C38, C45, C48, C51, Royal, Windsor, Newport, 5 tonner, US Army
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 98.425 | 50.8 | 21.828125 | 3 7/16 | 3 7/8 | 2 | 55/64 |
1 cyl piston set 10165 for Ford - 10 h.p. 1172cc SV Prefect, Export Anglia, 10cwt. Heplex version of 8743
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
4 cyl piston set 10453 for Scammell - 10 H.P., MH3, 3 Ton, H'Lex
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 38.89375 | 15.875 | 2 1/2 | 2 3/4 | 1 17/32 | 5/8 |
4 cyl piston set 10566 for Morris - Oxford Taxi 1803cc OHV, 13.93h.p.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 2.952756 | 0 | 0 | 0 |
4 cyl piston set 10995 for Wisconsin - 6HP, AEH 1 Cyl. 4 Cyl: VE4, Air Cooled. Aluminium Version.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.2 | 85.725 | 38.1 | 19.05 | 3 8.8817841970013E-16/2 | 3 3/8 | 1 1/2 | 3/4 |
4 cyl piston set 11276 for Ford - 30h.p 3622 cc S.V. 3.6 Litre Pilot V8, CR 6.15 to 1 (British Bullet Engine)
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
4 cyl piston set 11582 for Morris - 10h.p. 1140 cc Series M, SM, Ten Four
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
4 cyl piston set 12211 for Morris - 24.8h.p. 3519 cc S.V. C, CD, CV, Series 1 1/2 - 5 Ton, 3770 cc S.V., FV, NCV, Series, 3.77 Litre, 5 Ton, H'lex for 5246
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
100 | 107.95 | 57.15 | 26.9875 | 3.937008 | 4 1/4 | 2 1/4 | 1 1/16 |
1 cyl piston set 12417 for Austin - 8h.p. 900 cc Big Seven/New Eight, C.R. 6.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.769 | 63.5 | 31.75 | 12.7 | 2.235 | 2 1/2 | 1 1/4 | 1/2 |
1 cyl piston set 12572 for Austin - 18.9h.p. 2660 cc O.H.V. Atlantic A90/Healey Hundred, 2.7 Lit. CR 7.5 to 1. 4 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
4 cyl piston set 12621 for Austin - 803 cc OHV A30, Seven, High Comp CR 7.9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57.912 | 65.0875 | 33.3375 | 14.2875 | 2.28 | 2 9/16 | 1 5/16 | 9/16 |
4 cyl piston set 12847 for Morris - 1954-56, 13.2h.p. 1489 cc OHV Oxford Series II, 1 1/2 Litre, High Comp 8.2 to 1. 1957-8, OHV Cowley 1500, Oxford Series III, 1 1/2 Litre, CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
6 cyl piston set 13099 for Rover - 16.6h.p. 2230 cc 75, CR 7.2 to 1, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 105.3846 | 74.422 | 22.225 | 2 7/8 | 4.149 | 2.93 | 7/8 |
1 cyl piston set 13598 for Austin - 1489 cc OHV A50 Cambridge, High Comp CR 8.2 to 1. A50/A55 CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
4 cyl piston set 14022 for Volkswagen - 1192 cc OHV: 1200, 15 cwt. Van, Kombi, Microbus, RWD Air Cooled, Low Comp CR 6.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 80 | 38 | 20 | 3.031496 | 3.149606 | 1.496063 | 0.787402 |
6 cyl piston set 14635 for Mercedes - 3794 cc OHV Majestic, 3.8 litre, CR 7.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.35238 | 87.709375 | 47.0408 | 22.225 | 3.3997 | 3 29/64 | 1.852 | 7/8 |
4 cyl piston set 14978 for Fiat - 633 cc OHV 600, Multipla, RWD.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
60 | 63.25 | 40.75 | 18 | 2.362205 | 2.490157 | 1.604331 | 0.708661 |
4 cyl piston set 15878 for Skoda - 1089 cc OHV Octavia, CR 7.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
68 | 78 | 40 | 18 | 2.677165 | 3.070866 | 1.574803 | 0.708661 |
4 cyl piston set 16178 for Triumph - 1147 cc OHV Herald 1200, Herald 12/50, Spitfire, Courier 5 cwt. CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.28866 | 74.3458 | 38.4556 | 20.6375 | 2.7279 | 2.927 | 1.514 | 13/16 |
4 cyl piston set 16218 for MG - 1622 cc OHV MGA 1600 MkII, Magnetto Mk IV, Low Comp CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.1873 | 76.99375 | 42.06875 | 19.05 | 2.9995 | 3 1/32 | 1 21/32 | 3/4 |
4 cyl piston set 16236 for Volkswagen - 1493 cc OHV 1500N, RWD Air Cooled, 311 motor CR 7.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
83 | 83 | 40 | 22 | 3.267717 | 3.267717 | 1.574803 | 0.866142 |
4 cyl piston set 16494 for Renault - 1963-66 1108 cc OHV R8, 1100, Major, Caravelle, 1133, CR 8.5 to 1. 1965-66 R8 1100 Gordini, R8 Automatoc, CR 10.4 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70 | 68 | 40 | 18 | 2.755906 | 2.677165 | 1.574803 | 0.708661 |
1 cyl piston set 16854 for Fiat - 2279 cc OHV 2300, 114 Engine, CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
78 | 85.3 | 42.3 | 22 | 3.070866 | 3.358268 | 1.665354 | 0.866142 |
4 cyl piston set 17271 for Austin - 1275 cc OHV Healey Sprite, MkIV. CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.612 | 69.6849 | 38.0365 | 20.6375 | 2.78 | 2.7435 | 1.4975 | 13/16 |
1 cyl piston set 17308 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 17374 for Vauxhall - 1964/6 1057 cc OHV Viva, CR 8.5 to 1 (7.5 when thick gasket fitted). 1966 OHV Viva 90, CR 9 to 1, Steel Strut design
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74.295 | 75.565 | 37.6174 | 20 | 2.925 | 2.975 | 1.481 | 0.787402 |
4 cyl piston set 17483 for Datsun - 1595 cc OHV Bluebird 1600, DR411, Fairlady 1600 SP311 CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.2 | 88 | 45 | 22 | 3.433071 | 3.464567 | 1.771654 | 0.866142 |
4 cyl piston set 17563 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 17568 for Vauxhall - 1599 cc OHC Victor 1600, Viva 1600 SL, Firenza 1600 De Luxe SL, CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.7 | 83.312 | 45.3136 | 25.4 | 3.374016 | 3.28 | 1.784 | 1 |
4 cyl piston set 18005 for Austin - 1485 cc OHC Maxi 1500. 1.5 Litre. CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.2 | 74.8284 | 43.0784 | 20.6375 | 3 8.8817841970013E-16/2 | 2.946 | 1.696 | 13/16 |
1 cyl piston set 18212 for Citroen - 1985 cc OHV DS19, DS20, ID19, ID20, Pallas
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86 | 105.2 | 66.7 | 25 | 3.385827 | 4.141732 | 2.625984 | 0.984252 |
4 cyl piston set 18496 for Hillman - 1498 cc OHV Avenger Grand Luxe, GT CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.12124 | 75.803125 | 44.053125 | 23.8125 | 3.3906 | 2 63/64 | 1 47/64 | 15/16 |
4 cyl piston set 18515 for Austin - 997 cc OHV Seven Cooper CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
62.4205 | 63.2968 | 31.5468 | 15.875 | 2.4575 | 2.492 | 1.242 | 5/8 |
4 cyl piston set 18645 for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1 Uprated 711M Engine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18648 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 cwt Van, Low Comp. CR 8 to 1 uprated 711M Engine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18684 for Ford - 1599 cc OHV Cortina 1600, 1600GT, Capri 1600, 2737E Engine, CR 9 to 1. 1599 cc OHV Capri 1600GT CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 18733 for Jaguar - 4235 cc OHC E Type GT , E Type 2+2, 420, 420G, XJ6 4.2 Litre. CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
92.075 | 100.8634 | 52.5526 | 22.225 | 3 5/8 | 3.971 | 2.069 | 7/8 |
1 cyl piston set 18853 for Wartburg - 991 cc Knight, Two Stroke. CR 7.5 to 1, 3 Cylinder
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.5 | 95.3 | 58.3 | 20 | 2.893701 | 3.751969 | 2.295276 | 0.787402 |
1 cyl piston set 19061 for Opel - 1584 cc OHC, 1.6 Manta, 1.6 Asconda, CR 8.5 to 1. 1.6S manta, 1.6S Asconda, CR 9.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85 | 87 | 45 | 23 | 3.346457 | 3.425197 | 1.771654 | 0.905512 |
6 cyl piston set 19132 for Ford - 2494 cc OHV Consul, Consul L, Granada, Granada GXL, 2.5 litre V6 CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.346 | 52.1716 | 23.8125 | 3.6869 | 3.99 | 2.054 | 15/16 |
6 cyl piston set 19178 for Triumph - 1998 cc OHV 2000 Mk II from engine 50001, GT6 Mk III from Engine 10001, CR 8.85 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74.6887 | 81.7118 | 45.8216 | 20.6375 | 2.9405 | 3.217 | 1.804 | 13/16 |
2 cyl piston set 19298 for Ford - 6 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
2 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 19376 for Hillman - 1498 cc OHV Avenger Grand Luxe, GT, High Comp. CR 9.8 to 1. Avenger Tiger High Comp CR 10 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.12124 | 75.7682 | 44.1198 | 23.8125 | 3.3906 | 2.983 | 1.737 | 15/16 |
4 cyl piston set 19471 for Chrysler, Hillman - 1598 cc OHV Avenger 1600 GLS/TC. High Comp CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.33536 | 75.7682 | 44.1198 | 23.8125 | 3.4384 | 2.983 | 1.737 | 15/16 |
1 cyl piston set 19659 for Nissan - 988 cc A10 Engine. 79-81; Cherry 1.0 L, GL. 70-76; Cherry 100A Deluxe L. 76-79; Chery F11, GLS. 66-70; Sunny 1000. CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73 | 67.5 | 32.6 | 17.45 | 2.874016 | 2.65748 | 1.283465 | 0.687008 |
1 cyl piston set 19717 for Volvo - 4 cyl 1986 cc OHV: 142 from Engine 393950, 144 from Engine 428000, 145 from Engine 21050, B20A, B20F Engines. CR 8.7 to 1. B20E Engine, CR 10.2 to 1. 6 Cyl, 6...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.9 | 71 | 46 | 24 | 3 1/2 | 2.795276 | 1.811024 | 0.944882 |
2 cyl piston set 19750 for Volvo - 4 Cyl, 1986 cc OHV 142, 142E, 144, 144E, 145, 142S, 144S, 145S, 144DL, 145DL, 144GL, 1800E, 1800S, 1800ES, B20A, B20F, Engines, CR 8.7 to 1. B20B Engine, CR 9.5...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.89 | 71 | 46 | 22 | 3.499606 | 2.795276 | 1.811024 | 0.866142 |
1 cyl piston set 19829 for Honda - 89 cc OHC C90, CD90, CE90, S90
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
50 | 55 | 26.1 | 14 | 1.968504 | 2.165354 | 1.027559 | 0.551181 |
2 cyl piston set 19969 for Suzuki - 2 Cyl 184 cc GT185A/B/C/EC, ET185K, GT185L, GT185M Two Stroke
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
49 | 60 | 31.1 | 12 | 1.929134 | 2.362205 | 1.224409 | 0.472441 |
4 cyl piston set 20013 for Toyota - 1591 cc Corona Mk II, 1600 DX, 7R Engine. 1707 cc Corona Mk II, Van DX Mk II for LPG 6R Engine. 1858 cc Corona Mk II, Hard Top 1900GL, 8R-C, 8R Engine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86 | 84.75 | 39.75 | 22 | 3.385827 | 3.336614 | 1.564961 | 0.866142 |
4 cyl piston set 20140 for Triumph - 1296 cc 1300, Herald 13/60, Toledo, Dolomite 1300, CR 8.5 to 1. 1300 TC, Spitfire (Engine RD19477 On), CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.6473 | 66.9671 | 38.4937 | 20.6375 | 2.8995 | 2.6365 | 1.5155 | 13/16 |
4 cyl piston set 20201 for Opel - 1196 cc Kadett, L/Coupe/Caravan L, Rallye Kadett, Manta, Ascona, 1.2S, Kadette City, CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79 | 76 | 38 | 20 | 3.110236 | 2.992126 | 1.496063 | 0.787402 |
1 cyl piston set 20229 for Datsun, Nissan - A14 Engine; Datsun 1396 cc B210, Nissan 1397 cc Sunny 140Y Coupe, GL Estate, Violet 1.4 GL, California 210, Cherry, Pulsar. CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76 | 67.5 | 32.6 | 19 | 2.992126 | 2.65748 | 1.283465 | 0.748031 |
4 cyl piston set 20295 for Chrysler - 928 cc OHC Sunbeam, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.98462 | 52.3113 | 26.9621 | 17.4625 | 2.7553 | 2.0595 | 1.0615 | 11/16 |
1 cyl piston set 20358 for Suzuki - 2 Cyl, 247 cc GT250M, A, B, C. 3 Cyl, 371 cc GT380 J, K, L, M, A, B
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
54 | 68.5 | 32.6 | 14 | 2.125984 | 2.69685 | 1.283465 | 0.551181 |
4 cyl piston set 20396 for Austin - 998cc Austin/ Morris Mini MkII 1000 OHV, Mini Clubman 1000/MkII 1100 OHV, Riley Elf, Wolseley Hornet. All CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 65.7733 | 34.0868 | 15.86738 | 2.542 | 2.5895 | 1.342 | 0.6247 |
4 cyl piston set 20550 for Ford - 1298 cc OHV Escort 8 cwt Van, Capri 1300, Cortina 1300, Escort 1300, Popular 1300, Ghia 1300, Sport 1300, Fiesta 1300. 751M Engine, High Comp, CR 9 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 20557 for Yamaha - 123 cc DT 125 Trail, DT125 E, DT125 F, CR 6.7 to 1, Two Stroke
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56 | 66.1 | 33.2 | 16 | 2.204724 | 2.602362 | 1.307087 | 0.629921 |
4 cyl piston set 20755 for Austin, Morris - 1275 cc A Plus Engine, Austin OHV Metro 1.3 S, HLS, Maestro 1.3L, HLE, Allegro 1.3. Morris Ital 1.3 L, HL, HLS. CR 9.4 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.6247 | 70.485 | 38.7985 | 20.6375 | 2.7805 | 2.775 | 1.5275 | 13/16 |
1 cyl piston set 20773 for Austin, Mini, Morris, Riley, Wolseley - 998 cc Austin: 1968/9 Mini Mk II 1000. 1980 Onwards Metro 1000. Mini: 1970 onwards Clubman 1000, Mk II. Morris: 1968/9 Mini Mk II...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 65.7733 | 34.0868 | 15.86738 | 2.542 | 2.5895 | 1.342 | 0.6247 |
4 cyl piston set 21076 for Leyland - 1695 cc 'O' Series Engine OHC, Sherpa 200/230/250/255 CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.4423 | 72.04964 | 42.09796 | 20.6375 | 3.3245 | 2.8366 | 1.6574 | 13/16 |
4 cyl piston set 21127 for Leyland - 1993 cc O Series Engine, OHC, Freight Rover Sherpa 2000, CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.4423 | 60.25 | 35.3 | 20.65528 | 3.3245 | 2.372047 | 1.389764 | 0.8132 |
1 cyl piston set 21380 for Jaguar - 4235 cc 4.2 Litre Engine, OHC 420 E type, Mk X, XJ6 4.2, XJ6 Series III. CR 8.7 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
92.075 | 85.48878 | 41.5036 | 22.23008 | 3 5/8 | 3.3657 | 1.634 | 0.8752 |
4 cyl piston set 21486 for Mazda - 1490 cc E5 Engine 323 1500GT, CR 10 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 3.031496 | 0 | 0 | 0 |
1 cyl piston set 23700 for Ford - 1769 cc Sierra 1.8, Sierra L/LX/ GL/ GLX, Sierra Saphire L/LX/GL/GLX, HL1.8H CVH Engine, CR 9.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.94 | 63.059 | 33.1 | 26 | 3.147244 | 2.482638 | 1.30315 | 1.023622 |
6 cyl piston set 91513 for Perkins - 3 Cyl 2.36 litre P3, 144. 4 Cyl 3.15 Litre, PA, PB, P4, 4.192. 6 Cyl 4.73 Litre PF, PG, P6, 6.288. Diesel, with original ring equipment
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.9254 | 107.7722 | 57.0484 | 31.75 | 3.501 | 4.243 | 2.246 | 1 1/4 |
1 cyl piston set 234415 for Lister - HA, HB, HW Series, Diesel. CR 15.2 to 1. Water Cooled diameter is 4", Air Cooled is 4.002
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
101.6 | 127 | 73.0885 | 36.5125 | 4 | 5 | 2.8775 | 1 7/16 |
6 cyl piston set 350067 for Ford - 4D 240 cubic inches, D Series, 2701E Vertical, 2706E Inclined. 6D 360 cubic inches, D Series 2704E Vertical, 2709E Inclined. Diesel, CR 16.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
104.775 | 118.11 | 71.0311 | 34.925 | 4 1/8 | 4.65 | 2.7965 | 1 3/8 |
6 cyl piston set 350227 for Ford - 6571 cc 401 Cu. In, 6 cyl Dexta Tractor, Series 6Y, 8000, Series 7A, 8600, 8700. CR 16 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
106.69778 | 126.9746 | 68.1228 | 38.1 | 4.2007 | 4.999 | 2.682 | 1 1/2 |
4 cyl piston set 350321 for Opel - 2260 cc 2.3D Engine, Rekord 2.3D, L, Berlina, 2.3D caravan, Diesel, CR 22 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
92 | 89.65 | 53.75 | 30 | 3.622047 | 3.529528 | 2.116142 | 1.181102 |
1 cyl piston set 350482 for Austin, Leyland, Perkins - 1994 cc Prima 65 Engine, Austin Maestro 2.0D, 500-700, City L Van, Maestro Clubman, DLX. Leyland Sherpa 200 Series, Crewbus Van. Perkins 4.20...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.4423 | 77.09916 | 48.26 | 28 | 3.3245 | 3.0354 | 1.9 | 1.102362 |
4 cyl piston set 497301 for Bedford - 3614 cc OHV 220 Engine 3.6 Litre. 4 Cyl, CR 17 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
103.175 | 118.237 | 71.501 | 34.925 | 4.062008 | 4.655 | 2.815 | 1 3/8 |
6 cyl piston set 664278 for Fiat - 2279 cc OHV 2300, Engine Type 114B, CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
78 | 85.3 | 42.3 | 22 | 3.070866 | 3.358268 | 1.665354 | 0.866142 |
6 cyl piston set 666973 for Fiat - 652 cc 126A, 126BB Engine, 2 Cyl, Air cooled. CR 7.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 3.031496 | 0 | 0 | 0 |
4 cyl piston set 768110 for Simca - 1118 cc 1100, 1100L, 1100S, 350 Engine, CR 8.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74 | 67 | 40 | 22 | 2.913386 | 2.637795 | 1.574803 | 0.866142 |
4 cyl piston set 12587 JP for Austin - 8.3h.p. 803cc O.H.V. A30/Seven, CR 7.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57.912 | 65.0875 | 33.3375 | 14.2875 | 2.28 | 2 9/16 | 1 5/16 | 9/16 |
