1 cyl piston 12587 for Austin - 8.3h.p. 803cc O.H.V. A30/Seven, CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 57.912 | 65.0875 | 33.3375 | 2.28 | 2 9/16 | 1 5/16 | ||
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Ford
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
Land Rover 2 1/4 Diesel S2 and S3
3.562" Bore Size STD plus oversizes
same as 350001 pistons
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 100.0252 | 58.5978 | 30.1625 | 3.562 | 3.938 | 2.307 | 1 3/16 |
Rover P6
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 88.2396 | 56.515 | 25.4 | 3 3/8 | 3.474 | 2.225 | 1 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
4 cyl piston set 2292 for Dennis - 30h.p. Lance, Lancet 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 110 | 129.38125 | 64.29375 | 31.75 | 4.330709 | 5 3/32 | 2 17/32 | 1 1/4 |
4 cyl piston set 3889 for Morris - 19.2h.p. R, TX, 2 ton, Economy model
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 44.45 | 95.25 | 22.225 | 3.464567 | 1 3/4 | 3 3/4 | 7/8 |
4 cyl piston set 4376 for Renault - 12h.p. 1463cc Airline, YN2 Aluminium version of piston 4831
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70 | 78.5 | 43.5 | 18 | 2.755906 | 3.090551 | 1.712598 | 0.708661 |
1 cyl piston set 5055 for Fiat - 17h.p. 2516cc 518, Ardita 2000, Type O
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82 | 102 | 48 | 24 | 3.228346 | 4.015748 | 1.889764 | 0.944882 |
4 cyl piston set 5359 for Ford - 8Y
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.642 | 2.23 | 0 | 0 | 0 | |||
4 cyl piston set 7058 for Albion - 22.5h.p. HL126, J127, JS127, JL127, KN126, KL126, KS127, KN127, KL127, 70/80/90/100/110cwt, PH, PK114, 115, 24/36 seater passenger, Victor, EN212, EN68A, EN215,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 98.425 | 44.45 | 28.575 | 3 3/4 | 3 7/8 | 1 3/4 | 1 1/8 |
4 cyl piston set 7557 for Commer - 13.95h.p. 15, 20, 25cwt NI Series A Q15, Q25
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
6 cyl piston set 7650 for Perkins - 14.7h.p. 2.36 litre Python 3 cyl, 19.6h.p. 3.15 litre PA, FB, P4, Puma 4 cyl, 29.4h.p. 4.73 litre PF, PG, P6 Panther 6 cyl Diesel (1500rpm max)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9254 | 107.95 | 57.15 | 31.75 | 3.501 | 4 1/4 | 2 1/4 | 1 1/4 |
4 cyl piston set 7681 for Vauxhall - 10h.p. 1203cc Ten Four, H, C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 75.40625 | 39.6875 | 15.875 | 2 1/2 | 2 31/32 | 1 9/16 | 5/8 |
4 cyl piston set 7686 for Standard - 12h.p. 1608cc, Twelve, Flying Twelve
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 78.978125 | 39.290625 | 19.05 | 2.73622 | 3 7/64 | 1 35/64 | 3/4 |
4 cyl piston set 7751 for Standard - 9h.p. 1287cc Teinmouth Big Nine, C.R. 4.9 to 1, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 76.2 | 38.1 | 15.875 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
6 cyl piston set 7764 for Rover - 14h.p. 1577cc OHV, 14/6 Speed Pilot, Speed Fourteen
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61 | 33.3375 | 71.4375 | 14.2875 | 2.401575 | 1 5/16 | 2 13/16 | 9/16 |
4 cyl piston set 7789 for Ford - 10h.p. 10cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 64.29375 | 26.19375 | 17.4625 | 2 1/2 | 2 17/32 | 1 1/32 | 11/16 |
4 cyl piston set 7800 for Singer - 10h.p. 1185cc, Super Ten
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 68 | 33 | 14.2875 | 2.480315 | 2.677165 | 1.299213 | 9/16 |
6 cyl piston set 7812 for Morris - 14h.p. 1818cc Series II & III Fouteen Six 'Q'
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 79.5 | 42.5 | 18 | 2.42126 | 3.129921 | 1.673228 | 0.708661 |
4 cyl piston set 7817 for Standard - 12h.p. 1609cc, Flying Twelve, C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 82 | 45.5 | 19.05 | 2.73622 | 3.228346 | 1.791339 | 3/4 |
4 cyl piston set 8027 for Morris - 10h.p. 1140cc Series M, SM Ten Four
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
6 cyl piston set 8091 for Rover - 13.8h.p. 1577cc OHV Fourteen
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61 | 71.4375 | 33.3375 | 15.875 | 2.401575 | 2 13/16 | 1 5/16 | 5/8 |
4 cyl piston set 8152 for Vauxhall - 12h.p. 1442cc Twelve Four, I, C.R.6.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 93.6625 | 57.94375 | 15.875 | 2.73622 | 3 11/16 | 2 9/32 | 5/8 |
1 cyl piston set 8243 for Vauxhall - 14.6h.p. 1781cc fourteen Six from Engine No. DX 520001, Drilled con-rod type
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 75.40625 | 39.6875 | 19.05 | 2.42126 | 2 31/32 | 1 9/16 | 3/4 |
4 cyl piston set 8657 for Morris - LCS, LD, PW 15, 30cwt, 15.95h.p.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 80.9625 | 44.45 | 22 | 3.149606 | 3 3/16 | 1 3/4 | 0.866142 |
6 cyl piston set 8684 for Bedford - 20h.p. BYC, 12cwts C.R. 5.625 to 1. Aluminium Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 77.7875 | 41.275 | 22.225 | 2 7/8 | 3 1/16 | 1 5/8 | 7/8 |
4 cyl piston set 8743 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 30.95625 | 2 1/2 | 2 3/4 | 1 7/32 | ||
1 cyl piston set 8783 for Rover - 16.9h.p. 2147 cc Sixteen, 6 Cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.5 | 82.55 | 50.8 | 15.875 | 2.65748 | 3 1/4 | 2 | 5/8 |
6 cyl piston set 8860 for Bedford - 26.3h.p. WS, WH, WLG, WTH , WTL, WTB, BXC, 26 Seater Passenger 12/30/40/60cwt, Drilled con rod type. Aluminium Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.1375 | 93.6625 | 47.625 | 25.146 | 3 5/16 | 3 11/16 | 1 7/8 | 0.99 |
1 cyl piston set 8923 for Armstrong Siddeley - 17h.p. 2394cc OHV Sports
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.675 | 78.184375 | 40.084375 | 15.875 | 2 5/8 | 3 5/64 | 1 37/64 | 5/8 |
1 cyl piston set 9029 for Buick - 37.81h.p. M.O Type 60, 70, 80, 90 Series, Century, Roadmaster, Limited, 8 cylinder
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 113.50625 | 69.05625 | 22.225 | 3 7/16 | 4 15/32 | 2 23/32 | 7/8 |
8 cyl piston set 9155 for Buick - 37.81h.p. 60, 89, 90, 8 cylinder
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 104.775 | 58.7375 | 22.225 | 3 7/16 | 4 1/8 | 2 5/16 | 7/8 |
6 cyl piston set 9309 for Austin - 26.88h.p. 3459cc CX13, 1 1/2 to 5 ton, 20-26 seater passenger bus C.R. 5.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
1 cyl piston set 9534 for Armstrong Siddeley - 6/8h.p. Direct Injection, 4 1/4 Stroke, 1000 rpm, Air Cooled Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 107.95 | 115.57 | 66.04 | 31.75 | 4 1/4 | 4.55 | 2.6 | 1 1/4 |
6 cyl piston set 9844 for Chrysler - CO 6 cyl, 33.8h.p. Heston, Kingston, CT-CZ, C1-C50, Saratoga, New Yorker, Newport. Aluminium Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 98.425 | 50.8 | 21.828125 | 3 1/4 | 3 7/8 | 2 | 55/64 |
4 cyl piston set 10014 for Humber - 12h.p. 1669cc SV Twelve
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 92.67 | 51 | 22 | 2.73622 | 3.648425 | 2.007874 | 0.866142 |
6 cyl piston set 10170 for Bedford - 27.34h.p. 3519cc, series K, M, O, W, 3/4 to 5 Ton, Tractor 6 to 8 Ton, Cast Iron Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 85.725 | 41.275 | 20.6375 | 3 3/8 | 3 3/8 | 1 5/8 | 13/16 |
1 cyl piston set 10306 for Villiers - 147 cc Mark 15, 15HS. 208 cc Mark 20, 20HS
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 61.9125 | 33.3375 | 15.5448 | 2.480315 | 2 7/16 | 1 5/16 | 0.612 |
6 cyl piston set 10567 for Commer - 26.85h.p. 4086cc SV, LNF5, N5, PN4, PNF4, PNF5, CPNF5, Q2, Q3, Q4, Q5, 2-6 1/2 ton, 24 to 26 seater passenger, Commando, Tractor Trailer 6-10ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 93 | 51 | 24 | 3.346457 | 3.661417 | 2.007874 | 0.944882 |
2 cyl piston set 10895 for Wisconsin - TF, 2 Cyl. VF, V, 4 Cyl. Air Cooled
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 85.725 | 38.1 | 19.05 | 3 1/4 | 3 3/8 | 1 1/2 | 3/4 |
4 cyl piston set 11276 for Ford - 30h.p 3622 cc S.V. 3.6 Litre Pilot V8, CR 6.15 to 1 (British Bullet Engine)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
6 cyl piston set 11546 for Jaguar - 3442 cc , OHC 3.5 litre Xk120 MkVII, XK140 MkVII, type M, MkVIII, XK150 3.4, 3.4 litres Standard and MkII, High Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.99196 | 103.4161 | 55.0672 | 22.225 | 3.2674 | 4.0715 | 2.168 | 7/8 |
6 cyl piston set 11782 for Perkins - 5560 cc OHV R6, F340, Six 340S, 5.56 Litre, Diesel, CR 17.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 101.6 | 121.8946 | 74.215625 | 36.5125 | 4 | 4.799 | 2 59/64 | 1 7/16 |
4 cyl piston set 12016 for Ford - 3622 cc SV 3.6 litre, Pilot, V8, CR 6.15 to 1, H lex for 11276
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
4 cyl piston set 12417 for Austin - 8h.p. 900 cc Big Seven/New Eight, C.R. 6.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.769 | 63.5 | 31.75 | 12.7 | 2.235 | 2 1/2 | 1 1/4 | 1/2 |
4 cyl piston set 12541 for Austin - 10.6h.p. 1200 cc O.H.V. A40 Sports/A40 Somerset. CR 7.2 to 1. (RBP)
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4812 | 75.184 | 40.259 | 15.875 | 2.578 | 2.96 | 1.585 | 5/8 |
1 cyl piston set 12629 for Austin - 13.2h.p. 1489cc A50 Cambridge, CR 7.4 to 1, A50/A55 Low Comp CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
6 cyl piston set 12756 for Austin - 23.44h.p. 2639.4cc O.H.V. A90 Westminster 2.6 Lit/ A95 Low Comp. CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 87.3125 | 47.625 | 22.225 | 3 1/8 | 3 7/16 | 1 7/8 | 7/8 |
4 cyl piston set 13099 for Rover - 16.6h.p. 2230 cc 75, CR 7.2 to 1, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 105.3846 | 74.422 | 22.225 | 2 7/8 | 4.149 | 2.93 | 7/8 |
6 cyl piston set 13530 for Vauxhall - 23.44h.p. 2262 cc OHV 2 1/4 Litre, Velox, Cresta. Offset G Pin
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.375 | 79.0448 | 45.593 | 19.05 | 3 1/8 | 3.112 | 1.795 | 3/4 |
4 cyl piston set 14022 for Volkswagen - 1192 cc OHV: 1200, 15 cwt. Van, Kombi, Microbus, RWD Air Cooled, Low Comp CR 6.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 80 | 38 | 20 | 3.031496 | 3.149606 | 1.496063 | 0.787402 |
4 cyl piston set 14360 for Hillman - 1494 cc OHV, Minx 1 1/2 Litre Low Comp CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79 | 82.55 | 46.99 | 22.225 | 3.110236 | 3 1/4 | 1.85 | 7/8 |
4 cyl piston set 14978 for Fiat - 633 cc OHV 600, Multipla, RWD.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60 | 63.25 | 40.75 | 18 | 2.362205 | 2.490157 | 1.604331 | 0.708661 |
4 cyl piston set 15636 for Ford - 105E Opened Out to Give 1098 cc, CR 9.7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.0011 | 64.29375 | 38.89375 | 20.6375 | 3.3465 | 2 17/32 | 1 17/32 | 13/16 |
4 cyl piston set 16178 for Triumph - 1147 cc OHV Herald 1200, Herald 12/50, Spitfire, Courier 5 cwt. CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.28866 | 74.3458 | 38.4556 | 20.6375 | 2.7279 | 2.927 | 1.514 | 13/16 |
4 cyl piston set 16204 for Austin - 1098 cc OHV A40 MkII, 1100 Low Comp CR 7.5 to 1/ A35 6 Cwt Van, 7.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.1152 | 30.3276 | 15.875 | 2.542 | 2.288 | 1.194 | 5/8 |
4 cyl piston set 16300 for Opel - 1680 cc 4 Cyl, Olympia Rekord, 1.7 Litre, CR 7.25 to 1, Steel Strut Design
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 95 | 45 | 22 | 3.346457 | 3.740157 | 1.771654 | 0.866142 |
4 cyl piston set 16412 JP for Rover - 1998 cc 60, 2 Litre, CR 6.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.8 | 93.2942 | 61.5442 | 3.062992 | 3.673 | 2.423 | ||
1 cyl piston set 16854 for Fiat - 2279 cc OHV 2300, 114 Engine, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78 | 85.3 | 42.3 | 22 | 3.070866 | 3.358268 | 1.665354 | 0.866142 |
1 cyl piston set 17308 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 17483 for Datsun - 1595 cc OHV Bluebird 1600, DR411, Fairlady 1600 SP311 CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.2 | 88 | 45 | 22 | 3.433071 | 3.464567 | 1.771654 | 0.866142 |
4 cyl piston set 17569 for Vauxhall - 1599 cc OHC Victor 1600, Viva 1600 SL, Firenza 1600 De Luxe SL, Low Comp, CR 7.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.7 | 81.8388 | 43.8404 | 25.4 | 3.374016 | 3.222 | 1.726 | 1 |
2 cyl piston set 18242 for Volvo - 4 Cyl, 1986 cc OHV 142, 142E, 144, 144E, 145, 142S, 144S, 145S, 144DL, 145DL, 144GL, 1800E, 1800S, 1800ES, B20A, B20F, Engines, CR 8.7 to 1. B20B Engine, CR 9.5...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.89 | 71 | 46 | 22 | 3.499606 | 2.795276 | 1.811024 | 0.866142 |
4 cyl piston set 18515 for Austin - 997 cc OHV Seven Cooper CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 62.4205 | 63.2968 | 31.5468 | 15.875 | 2.4575 | 2.492 | 1.242 | 5/8 |
1 cyl piston set 18679 for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1, 2733E Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18742 for Triumph - 1709 cc OHC, CR 8.8 to 1 from Engine JBB7510
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83.48726 | 64.5668 | 34.0868 | 22.225 | 3.2869 | 2.542 | 1.342 | 7/8 |
4 cyl piston set 19064 for Land Rover - 2286 cc OHV Series II, IIA, III, 2 1/4 Litre CR 7 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 100.0252 | 58.4454 | 25.4 | 3.562 | 3.938 | 2.301 | 1 |
6 cyl piston set 19188 for Rover - 2995 cc 3 litre, Mk I, II and III, CR 8.75 to 1. 2625 cc 100, 2.6 litre CR 7.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.8 | 98.0186 | 66.3702 | 22.225 | 3.062992 | 3.859 | 2.613 | 7/8 |
2 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
1 cyl piston set 19472 for Chrysler - 1598 cc OHV Avenger 1600 GLS/TC. Low Comp CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.33536 | 75.7682 | 44.1198 | 23.8125 | 3.4384 | 2.983 | 1.737 | 15/16 |
2 cyl piston set 19717 for Volvo - 4 cyl 1986 cc OHV: 142 from Engine 393950, 144 from Engine 428000, 145 from Engine 21050, B20A, B20F Engines. CR 8.7 to 1. B20E Engine, CR 10.2 to 1. 6 Cyl, 6...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 71 | 46 | 24 | 3 1/2 | 2.795276 | 1.811024 | 0.944882 |
1 cyl piston set 19885 for Jaguar - 4235 cc Jaguar OHC MkX, E Type GT, E type 2+2, 420, 420 G, XJ 6 4.2 Litre, XJ 4.2, CR 9 to 11
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 100.8634 | 52.5526 | 22.225 | 3 5/8 | 3.971 | 2.069 | 7/8 |
4 cyl piston set 20015 for Toyota - 1897 cc 3R and 3R-B Engines, Crown, Stout, RS30, RS31, RS40, RS46
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 91 | 41 | 24 | 3.464567 | 3.582677 | 1.614173 | 0.944882 |
4 cyl piston set 20202 for Opel - 1698 cc 1.7 litre Rekord, Caravan, CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 87 | 45.1 | 23 | 3.464567 | 3.425197 | 1.775591 | 0.905512 |
6 cyl piston set 20296 for Rover, Triumph - 2350 cc OHC, 2.3 Litre, CR 9.25 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 81 | 70 | 40.1 | 23.8125 | 3.188976 | 2.755906 | 1.57874 | 15/16 |
1 cyl piston set 20397 for Austin, Morris - 1098 cc Austin A40 MkII 1100 OHV/Allegro 1100 De Luxe, Morris 1100/Minor 1000 OHV. 'A' Series Engine CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 58.0517 | 30.3276 | 15.86738 | 2.542 | 2.2855 | 1.194 | 0.6247 |
4 cyl piston set 20611 for Ford - 1600 cc OHV Fiesta USA Version
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 81.71688 | 42.11828 | 20.6375 | 3.1884 | 3.2172 | 1.6582 | 13/16 |
4 cyl piston set 20841 for Lancia - 1298 cc 813.302, 818.303 Engines, 85/87/89/92h.p. Fulvia Coupe Rallye 1.3, Fulvia Sport 1.3, Zagato, Fulvia GTF, Fulvia Berlina, Fulvia Coupe 1.3 S, Monte...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77 | 80.9 | 45.9 | 22 | 3.031496 | 3.185039 | 1.807087 | 0.866142 |
1 cyl piston set 21135 for Suzuki - 123 cc 1 Cyl TS125 C, C2, ERN, ERT, ERZ
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 66 | 32.5 | 14 | 2.204724 | 2.598425 | 1.279528 | 0.551181 |
1 cyl piston set 21776 for Suzuki - 970 cc F10A Engine, OHC Jimny SJ410/Q/V, 4WD, 110S40FK, 1000SJ40VC CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 2.57874 | 0 | 0 | 0 | |||
4 cyl piston set 158809 for Petter - AV1, AVA1, AV2, AVA2, Series II, AH1, Diesel. Water Cooled Bore is 80 mm, Air Cooled is 80.101mm
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 106 | 63.5 | 30 | 3.149606 | 4.173228 | 2 1/2 | 1.181102 |
1 cyl piston set 350024 for Ford - 4D 250 Cubic inches, D Series, 2701E Engine Vertical, 2706E Inclined 4 cylinder. 6D 360 cubic inches, D series 2704E Vertical, 2709 inclined 6cyl, Diesel. CR...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 104.775 | 118.26875 | 71.040625 | 34.925 | 4 1/8 | 4 21/32 | 2 51/64 | 1 3/8 |
1 cyl piston set 350175 for Mercedes - 10809 cc OM346 Engine, 180/210h.p., Direct Injection Diesel, CR 17.5 to 1. LKA/L)1418, 1518, 1618, 1619, 1620, 1918, 1920, 2020, 2220, 2620, 0317, LS332, L334
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 128 | 161.417 | 85.268 | 44 | 5.03937 | 6.355 | 3.357008 | 1.732283 |
1 cyl piston set 350268 for Petter - PJ MkII, PJW Ser, Air and Water cooled Multi Cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 96.8756 | 105.9942 | 63.59906 | 30 | 3.814 | 4.173 | 2.5039 | 1.181102 |
1 cyl piston set 350382 for Ford - 3294 cc 201 cu.in, 3 cyl, Series 6Y, Major 4000 Tractor, Series 7A, 4600. Also BSD333H/BSD444 Engine, Direct injection 4610, 4610SU Tractors, 6610, 6710...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 111.77778 | 127 | 68.1228 | 38.1 | 4.4007 | 5 | 2.682 | 1 1/2 |
4 cyl piston set 350979 for Ford - 1753 cc 59h.p, Courier 1.8D Van, Escort 1.8D (35/55 Combi Van, 40/60/55/75 Van, GLX/Ghia/L/LX/L Business, Popular, Encore, Popular Plus, LD/GLD), Fiesta 1.8D...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 73.5 | 45.7 | 26 | 3.248031 | 2.893701 | 1.799213 | 1.023622 |
6 cyl piston set 517803 for Ford - 5 Cyl, 4D 240 cubic inches , D Series, 2701E Vertical, 2706E Inclined. 6 Cyl 6D 360 cubic inches, D series, 2704E Vertical, 2709E Inclined.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 104.775 | 118.26875 | 71.040625 | 34.925 | 4 1/8 | 4 21/32 | 2 51/64 | 1 3/8 |
1 cyl piston set 583206 for David Brown - 3 cyl 2695 cc 880, 885. 4 cyl 3594 cc 995/996/1200/1210/1212. Direct Injection Diesel. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
4 cyl piston set 665017 for Fiat - 1221 cc OHV 1100D Europa, 1200 Gran Luxe Spider, Engine type 103 G CR 8.1 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 82 | 46 | 22 | 2.834646 | 3.228346 | 1.811024 | 0.866142 |
4 cyl piston set 665733 for Fiat - 1197 cc OHV 124 Berlina Familiar,CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 80.05 | 40.55 | 22 | 2.874016 | 3.151575 | 1.596457 | 0.866142 |
4 cyl piston set 666298 for Fiat - 1290 cc 128, 1300 Saloon, Estate, Rally Special, Sport Coupe/L, 3P, X1/9, CR 8.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86 | 77.3 | 35.35 | 22 | 3.385827 | 3.043307 | 1.391732 | 0.866142 |
1 cyl piston set 667199 for Fiat - 1301 cc 138A1000 Ritmo 65L/CL, Targa oro, Strada 65L, CL
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 86.4 | 76.7 | 34.7 | 22 | 3.401575 | 3.019685 | 1.366142 | 0.866142 |
4 cyl piston set 667699 for Fiat - 1116 cc 138B.000 Engine, Ritmo 60L/CL, Strada 60 Comfort, Comfort CL, ES. Uno 55 Comfort, Super
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 75.15 | 35.5 | 22 | 3.149606 | 2.958661 | 1.397638 | 0.866142 |
4 cyl piston set 798110 for Renault - 845 cc R4, R4L, R5L, R6L, R6 850, 8 Cwt.Fourgon Van
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 58 | 64 | 30 | 16 | 2.283465 | 2.519685 | 1.181102 | 0.629921 |
4 cyl piston set 129.14.07 for Peugeot - 2304 cc XD2-XD2P-XD94 Engines, 504 GLD/Berline/Familiale, 505 GRD/SRD, J7 PX/PY/PZ, J9, CR 22.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 94 | 99.9 | 57.42 | 28 | 3.700787 | 3.933071 | 2.26063 | 1.102362 |
4 cyl piston set 789.11.08 for Renault - 1969-71 1289 cc OHV R10 1300 CR 8 to 1. 1970 On, 1289 cc OHV R12L, R12TL, R12TR, R12TS, R15TL, R5LS, R5TS, CR 9.5 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 62.7 | 37.7 | 20 | 2.874016 | 2.468504 | 1.484252 | 0.787402 |
