Morris
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 80.9625 | 44.45 | 22 | 3.149606 | 3 3/16 | 1 3/4 | 0.866142 |
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
4 cyl piston set 1296 for Morris - 15.9h.p. 2513cc Colonial, Z 30cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 44.45 | 94.45625 | 22.225 | 3.149606 | 1 3/4 | 3 23/32 | 7/8 |
1 cyl piston set 4046 for Villiers - 148cc Longstroke, Two Port, X11C, GY, Two-Stroke with Deflector
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
53 | 91.28125 | 51.59375 | 12.5 | 2.086614 | 3 19/32 | 2 1/32 | 0.492126 |
4 cyl piston set 5140 for Commer - 14h.p. 15, 20, 25cwt B20 NI
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 92.25 | 51 | 22 | 2.952756 | 3.63189 | 2.007874 | 0.866142 |
4 cyl piston set 7591 for Vulcan - 25.8h.p. Duchess 5VF, 6VF1/2/3 Tipper 5-6 ton
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
102 | 111.125 | 60.325 | 25.4 | 4.015748 | 4 3/8 | 2 3/8 | 1 |
6 cyl piston set 7683 for Vauxhall - 12h.p. 1531cc DY, Twelve Six, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57 | 75.40625 | 39.6875 | 19.05 | 2.244094 | 2 31/32 | 1 9/16 | 3/4 |
1 cyl piston set 7755 for Morris - 1931 14.9h.p. Major QX, 6 cyl, 1930 to 32 14.9h.p Oxford 6 cyl, 1933 to 34 Ten Four 4 cyl, 1934 - 1935 Fifteen Six
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
4 cyl piston set 7795 for Austin - 10h.p. 1125cc Ten Four, 6/10cwt, Triton Marine Engine, Model A, B
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 31.75 | 14.2875 | 2 1/2 | 2 3/4 | 1 1/4 | 9/16 |
4 cyl piston set 7815 for Standard - 10h.p. 1343cc Ten
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 78.184375 | 39.290625 | 19.05 | 2 1/2 | 3 5/64 | 1 35/64 | 3/4 |
4 cyl piston set 8041 for Triumph - 11.8h.p. 1496cc, 1.5 litre Dolomite
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69 | 85 | 45 | 19.05 | 2.716535 | 3.346457 | 1.771654 | 3/4 |
6 cyl piston set 8238 for Austin - 26.88h.p. 3459cc CX13 1 1/2 to 5 ton 20-26 seater passenger bus C.R 5.75 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
4 cyl piston set 8754 for Packard - 1937 British Model 115. 1935-1947 33.8h.p. 4620 cc 120, 120B, 120C, 120CD, 138CD, 1601, 1601A, 1601D, 1602, 1701, 1701A, 1702, 1801, 1801A, 1901, 1901A, 2001,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.55 | 98.425 | 53.975 | 22.225 | 3 1/4 | 3 7/8 | 2 1/8 | 7/8 |
1 cyl piston set 8909 for Daimler - 16.2h.p. 2166cc '15' DB17.1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.04 | 72 | 40 | 17.78 | 2.6 | 2.834646 | 1.574803 | 0.7 |
4 cyl piston set 9035 for Ford - 30h.p. Export V8, 18, 40, 48, 68, C.R 6.12 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7875 | 75.40625 | 38.89375 | 19.05 | 3 1/16 | 2 31/32 | 1 17/32 | 3/4 |
1 cyl piston set 9310 for Austin - 28.3h.p. 6 wheeler 4-wheel drive, twin rear axle K3/YF, 4-wheel drive K3/ZD, K5. Aluminium piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 93.6625 | 47.625 | 22.225 | 3 7/16 | 3 11/16 | 1 7/8 | 7/8 |
4 cyl piston set 9984 for Singer - 9.93h.p. 1193cc Super 10, CR 7 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.246 | 68 | 33 | 14.2875 | 2.49 | 2.677165 | 1.299213 | 9/16 |
2 cyl piston set 10261 for Petter - 1 Cyl A1, 2 Cyl A2
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.5 | 82.86 | 40 | 19 | 3.444882 | 3.262205 | 1.574803 | 0.748031 |
1 cyl piston set 10567 for Commer - 26.85h.p. 4086cc SV, LNF5, N5, PN4, PNF4, PNF5, CPNF5, Q2, Q3, Q4, Q5, 2-6 1/2 ton, 24 to 26 seater passenger, Commando, Tractor Trailer 6-10ton
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85 | 93 | 51 | 24 | 3.346457 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 10931 for Hillman - 1265 cc Minx Mark IV, V, VI, VII, SV, Husky, MkI, CR 6.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65.0875 | 73.92 | 39 | 17.4625 | 2 9/16 | 2.910236 | 1.535433 | 11/16 |
1 cyl piston set 11433 for International - Farmall M, MV, I6, IU6, O6, OS6, T6, W6, Power Unit U6, High Comp for 9591
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
98.425 | 146.05 | 90.4875 | 33.3375 | 3 7/8 | 5 3/4 | 3 9/16 | 1 5/16 |
4 cyl piston set 11581 for Morris - 6 cyl 14.9h.p. Major QX, Oxford, Fifteen Six. 4 Cyl Ten Four
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 71.5 | 35 | 16 | 2 1/2 | 2.814961 | 1.377953 | 0.629921 |
6 cyl piston set 11848 for Fordson - 3610 cc OHV Major Tractor, Vaporising Oil, CR 4.35 to 1, 24.8h.p. OHV Cost Cutter, 1 1/2 - 4 Ton, Petrol
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
99.9998 | 117.9576 | 71.0438 | 31.75 | 3.937 | 4.644 | 2.797 | 1 1/4 |
1 cyl piston set 12064 for AEC - A312, 5.123 Lit. 4Cyl. 1685cc. AV470/AH470/Regent MkV/Reliance/Mercury/8 ton/7.75 Lit, 6 Cyl, Direct injection Diesel, C.R. 16 to 1 - RBP, H'lex Tin Plated
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
112 | 152.2476 | 91.9226 | 40 | 4.409449 | 5.994 | 3.619 | 1.574803 |
4 cyl piston set 12455 for Hudson, Nash - 1932-39, 3475 cc Big 6, Custom 6, Terra Plane 6. 4168 cc Great 8, Pacemaker 8, Special 8, Deluxe 8, Custom 8. Late 1939-56, 3310 cc SV Super 6, Commodore...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.2 | 80.9625 | 42.8625 | 19.05 | 3 8.8817841970013E-16/2 | 3 3/16 | 1 11/16 | 3/4 |
6 cyl piston set 12545 for Morris - 14h.p. 1818 cc Morris Series II and III, Fourteen Six, 'Q'
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61.5 | 70 | 42.5 | 18 | 2.42126 | 2.755906 | 1.673228 | 0.708661 |
4 cyl piston set 12650 for Standard, Triumph - 948 cc OHV Ten, Pennant, 6 cwt Van, Atlas 10/12 Cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63 | 66.1 | 38.1 | 15.875 | 2.480315 | 2.602362 | 1 1/2 | 5/8 |
6 cyl piston set 12768 for Austin - 4 cyl 2660 cc OHV Champ, 5 cwt. 6 cyl 3993 cc OHV 4 Litre , Loadstar, 2-5 ton/ 4x4 1 ton, 6 cyl.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
4 cyl piston set 13251 for Ford (American) - 1941-2 4Cyl 1NC/2NC/1ND/2ND/1NY/2NY, 1/2 - 1 Ton. 1939-47 32.5HP (95/100h.p. V8), (09/19/29/59/69/79/99)C, (09/29/69/79/99)D,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.9625 | 80.9625 | 45.24375 | 19.05 | 3 3/16 | 3 3/16 | 1 25/32 | 3/4 |
4 cyl piston set 13556 for Austin - 948 cc O.H.V. A35, A40 Healey Sprite, Low Comp CR 7.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 14136 for MG - 1250 cc OHV Midget, 1 1/4 Litre, Series TB, TC, TD, TF, Y, YA, YB
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.5 | 73 | 45 | 18 | 2.61811 | 2.874016 | 1.771654 | 0.708661 |
4 cyl piston set 14370 for Standard - 1009 cc SV Flying Eight, CR 6.7 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.7 | 73.025 | 38.1 | 15.875 | 2.232283 | 2 7/8 | 1 1/2 | 5/8 |
1 cyl piston set 15181 for Vauxhall - 2651 cc OHV 2.6 litre, Velox, Cresta
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.55 | 77.978 | 44.45 | 22.0091 | 3 1/4 | 3.07 | 1 3/4 | 0.8665 |
4 cyl piston set 15707 for Fiat - 767 cc OHV 600D, CR 7.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
62 | 62 | 31 | 20 | 2.440945 | 2.440945 | 1.220472 | 0.787402 |
1 cyl piston set 16216 for Austin - 1622 cc OHV A60, CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.1873 | 76.99375 | 42.06875 | 19.05 | 2.9995 | 3 1/32 | 1 21/32 | 3/4 |
4 cyl piston set 16309 for Wolseley - 998 cc OHV Hornet, CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 65.8368 | 34.0868 | 15.875 | 2.542 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 16422 for Volkswagen - 1493 cc OHV 1500S, RWD Air Cooled, 341 motor CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
83 | 88 | 45 | 22 | 3.267717 | 3.464567 | 1.771654 | 0.866142 |
4 cyl piston set 17012 for Austin, Morris - 1622 cc OHV Austin A60, Morris Oxford, CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.1873 | 76.99375 | 42.06875 | 19.05 | 2.9995 | 3 1/32 | 1 21/32 | 3/4 |
4 cyl piston set 17215 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7494 | 75.565 | 37.6174 | 3.061 | 2.975 | 1.481 |
4 cyl piston set 17309 for Ford - 4 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2495...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
4 cyl piston set 17363 for Audi - 1696 cc O.H.V. Audi 80/F103, 1700s-103 Engine. CR 11 to 1, SSD
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 72.5 | 43.5 | 24 | 3.149606 | 2.854331 | 1.712598 | 0.944882 |
4 cyl piston set 17490 for Opel - 4 cyl 1492 cc OHC Rekord, Caravan, 1.5 Litre. 6 Cyl 2239 cc OHC Rekord L, Commodore, Coupe, 2200. CR 8.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.5 | 87 | 45 | 23 | 3.248031 | 3.425197 | 1.771654 | 0.905512 |
4 cyl piston set 17560 for Ford - 1298 cc OHV Escort 1300GT, Capri 1300 GT, 2735E Engine, CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 17570 for Bedford - 1975 cc OHC CF 22/25/35 cwt. CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
95.25 | 81.8642 | 43.8658 | 25.4 | 3 3/4 | 3.223 | 1.727 | 1 |
1 cyl piston set 17916 for Triumph - 1964 1998 cc OHV 2000, CR 8.5 to 1. 1965/70 OHV 2000, CR 9 to 1. 1968 OHV 2000 PI, CR 9.5 to 1. 1967/1970 OHV Vitesse GT6, 2 Litre CR 9.5 to 1. 1968/70,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74.6887 | 74.1426 | 38.1 | 20.6375 | 2.9405 | 2.919 | 1 1/2 | 13/16 |
4 cyl piston set 18262 for Triumph - 1296 cc OHV 1300 CR 8.5 to 1, Spitfire CR 9 to 1 to Engine RD19476
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.6473 | 66.9671 | 38.4937 | 20.6375 | 2.8995 | 2.6365 | 1.5155 | 13/16 |
4 cyl piston set 18495 for Hillman - 1248 cc OHV Avenger, De Luxe, Super, CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
78.6003 | 75.803125 | 44.053125 | 23.8125 | 3.0945 | 2 63/64 | 1 47/64 | 15/16 |
4 cyl piston set 18519 for Austin - 948cc OHV Healey Sprite MkI. CR 9.35 to 1/ MkII 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
62.9285 | 65.8368 | 34.0868 | 15.875 | 2.4775 | 2.592 | 1.342 | 5/8 |
4 cyl piston set 18643 for Ford - 940 cc OHV Export Escort 940, CR 9.5 to 1, Uprated 711M Engine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18680 for Ford - 1098 cc OHV Escort 1100, 6/8 cwt Van. 2733E Engine, Low Comp CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18683 for Ford - 1298 cc OHV Escort 1300GT, Capri 1300 GT, 2735E Engine, CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18753 for Ford - 1593 cc OHC Cortina 1600 GT, Capri 1600/GT, Cortina 1600 L, Cortina 1600 XL, CR 9.2 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.65 | 73.1 | 41.2 | 24 | 3.450787 | 2.877953 | 1.622047 | 0.944882 |
4 cyl piston set 18802 for Austin - 1798 cc OHV 1800, 1800 HL, 1800 MkII/MkIII CR 9 to 1, 1800S MkII CR 9.5 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.23733 | 61.1124 | 42.164 | 20.6375 | 3.15895 | 2.406 | 1.66 | 13/16 |
4 cyl piston set 19105 for Hillman - 875 cc OHC Imp, Super Imp, Husky, Low Comp CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.2564 | 52.0573 | 26.67 | 15.875 | 2.766 | 2.0495 | 1.05 | 5/8 |
2 cyl piston set 19131 for Ford - 1969-71 1996 cc OHV Capri 2000GT, V4, CR 8.9 to 1. 1972 onwards 2994 cc OHV Capri, Consul GT, Granada, Granada GXL, 3 litre V6, CR 8.9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 95.25 | 46.1391 | 23.8125 | 3.6869 | 3 3/4 | 1.8165 | 15/16 |
1 cyl piston set 19270 for Standard, Triumph - 1961/3 - Standard OHV 2 litre, Vanguard Six, E30/1, CR 8 to 1. 1964/9 - Triumph 2000, CR 8.5 to 1. 1965/70 2000 to Engine 50000, CR 9 to 1. 1967/70 -...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74.6887 | 74.1426 | 38.1508 | 20.6375 | 2.9405 | 2.919 | 1.502 | 13/16 |
4 cyl piston set 19298 for Ford - 5 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
1 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
Mini Cooper
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.612 | 58.6105 | 38.0365 | 20.6375 | 2.78 | 2.3075 | 1.4975 | 13/16 |
4 cyl piston set 19557 for Audi - 1296 cc. Audi 60/80/80L. CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 77.5 | 45.5 | 22 | 2.952756 | 3.051181 | 1.791339 | 0.866142 |
4 cyl piston set 19657 for Toyota - 1591 cc 7R Engine, Corona Mk II, 1600 DX. 1707 cc 6R Engine, Corona Mk II, Van DX MkII for LPG. 1858 cc 8R Engine, Corona MkII, Hard Top 1900 GL, 8R-C
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86 | 84.75 | 39.75 | 22 | 3.385827 | 3.336614 | 1.564961 | 0.866142 |
4 cyl piston set 19724 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7494 | 75.6412 | 37.6936 | 20 | 3.061 | 2.978 | 1.484 | 0.787402 |
4 cyl piston set 19743 for Mitsubishi - 1439 cc 4G33 Engine, OHC 1400 Colt, Lancer, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73 | 69.7 | 32.7 | 19 | 2.874016 | 2.744094 | 1.287402 | 0.748031 |
1 cyl piston set 19913 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Popular 1300, Escort 8 cwt van, 751M Engine, Low Comp. CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
2 cyl piston set 19938 for Honda - 249 cc OHC CB250, CB250K2, CB250K3, CB250K4, CB250G5, CR 9.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56 | 62.5 | 32.1 | 15 | 2.204724 | 2.46063 | 1.26378 | 0.590551 |
1 cyl piston set 20118 for Austin - 1695 cc Leyland 'O' series engine - Sherpa 200/230/250/255. CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.4423 | 72.04964 | 42.09796 | 20.6375 | 3.3245 | 2.8366 | 1.6574 | 13/16 |
4 cyl piston set 20139 for Triumph - 1493 cc OHV 1500, CR 8.5 to 1. OHV 1500, 1500TC, Spitfire 1500, Dolomite 1500, 1500HL, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.6473 | 58.0898 | 32.6898 | 20.6375 | 2.8995 | 2.287 | 1.287 | 13/16 |
4 cyl piston set 20204 for Audi - 1093 cc. Audi 50/GLS/LS. CR 8/8.2 to 1, Pyrostrut design
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 67.2 | 40.3 | 20 | 2.73622 | 2.645669 | 1.586614 | 0.787402 |
4 cyl piston set 20228 for Datsun - 1288 cc B210 A13 Engine.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73 | 67.5 | 32.6 | 17.452 | 2.874016 | 2.65748 | 1.283465 | 0.687087 |
6 cyl piston set 20316 for Ford - 2.3 litre HF23 V6 Engine, OHV 20M, 2300S, 21M/TS 2300 S, 20M/RS, Cortina GL/S/Ghia, Taunus 2300 GXL/S/Sport/Coupe/Ghia, Capri 2300 GT/R, Capri II 2300 GT/S//Ghia,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
90 | 24 | 3.543307 | 0 | 0 | 0.944882 |
1 cyl piston set 20350 for Suzuki - 2 Cyl 398 cc DOHC GS400, GS400C, GS400EC, GS400N, GS400EN. 4 Cyl 750 cc DOHC GS750, C/DC/N/DN
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65 | 63.7 | 35.8 | 16 | 2.559055 | 2.507874 | 1.409449 | 0.629921 |
4 cyl piston set 20398 for Austin, Morris - 1098 cc 'A' Series Engine OHV 1100/Minor 1000/ 6 cwt Van/Marina 7 cwt Van, Low Comp CR 7.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 58.0517 | 30.3276 | 15.875 | 2.542 | 2.2855 | 1.194 | 5/8 |
4 cyl piston set 20548 for Ford - 1098 cc OHV Escort 6-8 cwt Van, Escorty 1100, Popular 1100, 751M Engine High Comp, CR 9 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20614 for Volvo - 4 Cyl, 1986 cc B20A, B20F Engines, OHV, 142, 142E, 144, 144 E, 145, 142 S, 144 S, 145 S, 144 DL, 145 DL, 144 GL, 1800 E, 1800 S, 1800 ES, CR 8.7 to 1. B20B...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.89 | 71 | 46.1 | 22 | 3.499606 | 2.795276 | 1.814961 | 0.866142 |
4 cyl piston set 20747 for Mini - 1275 cc OHV Cooper S, CR 9.75 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.612 | 58.6105 | 38.0365 | 20.6375 | 2.78 | 2.3075 | 1.4975 | 13/16 |
4 cyl piston set 20950 for Austin, Mini, Morris - 998 cc A Series Mini Cooper, CR 8.4/9.1 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 60.72124 | 33.8582 | 15.875 | 2.542 | 2.3906 | 1.333 | 5/8 |
4 cyl piston set 21075 for Austin - 1695 cc 'O' Series OHC Ambassador 1.7L/HL, Princess 1700L/HL/HLS, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.4423 | 73.37044 | 43.41876 | 20.64258 | 3.3245 | 2.8886 | 1.7094 | 0.8127 |
4 cyl piston set 21145 for Honda - 498 cc XL500, S/SZ/Z/A
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
89 | 65.2 | 29.2 | 21 | 3.503937 | 2.566929 | 1.149606 | 0.826772 |
4 cyl piston set 21262 for Vauxhall - 1598 cc 1.6N, 1.6S Engine, OHC Astra 1600L, GL, SR, Belmont 1600L, GL, GLS, Cavalier, L, GL, LX, SR, GLS. CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 72 | 40.05 | 23 | 3.149606 | 2.834646 | 1.576772 | 0.905512 |
4 cyl piston set 21813 for Nissan - 1595 cc L16 Engine. 1967-73; Bluebird 1600. 73-80; (P510). 73-80; Bluebird 160B (610, L610, LJ810, V610, VLJ810). 80-84; Bluebird 1.6 GL (TJ910, TLJ910)....
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
83 | 78 | 38.1 | 21 | 3.267717 | 3.070866 | 1 1/2 | 0.826772 |
4 cyl piston set 22304 for Opel - 1598 cc X1.6SZ Engine, Single Point Injection, Astra GL/GLS/CDX/Season/Club, CR 10.1 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79 | 48 | 28.05 | 18 | 3.110236 | 1.889764 | 1.104331 | 0.708661 |
4 cyl piston set 158809 for Petter - AV1, AVA1, AV2, AVA2, Series II, AH1, Diesel. Water Cooled Bore is 80 mm, Air Cooled is 80.101mm
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 106 | 63.5 | 30 | 3.149606 | 4.173228 | 2 1/2 | 1.181102 |
4 cyl piston set 230011 for Ferguson - 2259 cc OHV 35 Diesel CR 20 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.1756 | 98.2599 | 60.198 | 28.575 | 3.314 | 3.8685 | 2.37 | 1 1/8 |
1 cyl piston set 350026 for Petter - PAZI, Air Cooled, Diesel
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.2 | 92 | 55.042 | 27 | 3 8.8817841970013E-16/2 | 3.622047 | 2.167008 | 1.062992 |
4 cyl piston set 350051 for Ford - 4 cyl 2358 cc Transit 75/80/90/100/115/125/130/150/160/175/190, Vans 100, 150. York 2.4 litre. 3537 cc A Series. 6 cyl Parent Block Engine. Indirect Injection...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64472 | 108.0008 | 61.64834 | 28.99918 | 3.6868 | 4.252 | 2.4271 | 1.1417 |
1 cyl piston set 350185 for Bedford - 8.2 Litre 500 Engine Direct injection Diesel. CR 17 to 1, Al fin design RBP
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
115.8875 | 122.428 | 75.7936 | 44.45 | 4 9/16 | 4.82 | 2.984 | 1 3/4 |
4 cyl piston set 350269 for Leyland - 4 cyl 3.77 Litre Leyland 4/98 Series, 6 cyl 5.65 Litre 6/98, Normally Aspirated, Diesel, CR 16.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
98 | 116.3 | 68.25 | 36.5125 | 3.858268 | 4.57874 | 2.687008 | 1 7/16 |
1 cyl piston set 350384 for Ford - 2496 cc 2.5DI Engine, Diesel Direct Injection Transit, CR 19 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.67012 | 94.00032 | 59.48426 | 29.00426 | 3.6878 | 3.7008 | 2.3419 | 1.1419 |
4 cyl piston set 360001 for Fiat - 1116 cc OHC 128, 128 Sport Coupe 1100, L1100, 128 Special 1100, 128 3P 1100, CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 72.3 | 35.3 | 22 | 3.149606 | 2.846457 | 1.389764 | 0.866142 |
4 cyl piston set 583206 for David Brown - 3 cyl 2695 cc 880, 885. 4 cyl 3594 cc 995/996/1200/1210/1212. Direct Injection Diesel. CR 17 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
4 cyl piston set 665733 for Fiat - 1197 cc OHV 124 Berlina Familiar,CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73 | 80.05 | 40.55 | 22 | 2.874016 | 3.151575 | 1.596457 | 0.866142 |
4 cyl piston set 666708 for Fiat - 1297 cc 131.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76 | 78.45 | 38.95 | 22 | 2.992126 | 3.088583 | 1.533465 | 0.866142 |
4 cyl piston set 667234 for Fiat - 1301 cc 131B.000 OHC, 131 Supermirafiori, CR 8.9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.05 | 82.95 | 38.45 | 22 | 2.994094 | 3.265748 | 1.51378 | 0.866142 |
4 cyl piston set 674110 for Simca - 1290 cc OHV Aronde, Rush Engine, CR 7.5 to 1. Rush Super engine CR 8.5 to 1. 1300, 1301 CR 8.3 to 1. 1301GL, 1301LS CR 8.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74 | 78.5 | 42 | 22 | 2.913386 | 3.090551 | 1.653543 | 0.866142 |
4 cyl piston set 863120 for Simca - 1204 cc 1200S
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74 | 64.2 | 37.5 | 22 | 2.913386 | 2.527559 | 1.476378 | 0.866142 |
4 cyl piston set 11920 JP for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 129.44.37 for Peugeot - 2304 cc XD2 Engine, 504 GLD, 505 GRD, J7, J9, CR 22.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
94 | 99.9 | 57.42 | 30 | 3.700787 | 3.933071 | 2.26063 | 1.181102 |
