1 cyl piston 12587 for Austin - 8.3h.p. 803cc O.H.V. A30/Seven, CR 7.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57.912 | 65.0875 | 33.3375 | 2.28 | 2 9/16 | 1 5/16 |
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
TR4 (86mm std bore) +.040
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.98916 | 87.3125 | 50.8 | 22.225 | 3.3854 | 3 7/16 | 2 | 7/8 |
Land Rover 2 1/4 Diesel S2 and S3
3.562" Bore Size STD plus oversizes
same as 350001 pistons
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
90.4748 | 100.0252 | 58.5978 | 30.1625 | 3.562 | 3.938 | 2.307 | 1 3/16 |
Standard 12HP
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 78.978125 | 39.290625 | 19.05 | 2.73622 | 3 7/64 | 1 35/64 | 3/4 |
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
6 cyl piston set 2727 for Gardner - 36.5h.p. 70/90cwt 6JO ring below pin. Also Gilford
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
98.425 | 111.125 | 60.325 | 28.575 | 3 7/8 | 4 3/8 | 2 3/8 | 1 1/8 |
4 cyl piston set 3889 for Morris - 19.2h.p. R, TX, 2 ton, Economy model
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88 | 44.45 | 95.25 | 22.225 | 3.464567 | 1 3/4 | 3 3/4 | 7/8 |
4 cyl piston set 4674 for Ford - 10h.p.(Short) 1172cc SV Deluxe, C.E. Prefect,
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 65.0875 | 26.19375 | 17.4625 | 2 1/2 | 2 9/16 | 1 1/32 | 11/16 |
1 cyl piston set 5055 for Fiat - 17h.p. 2516cc 518, Ardita 2000, Type O
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82 | 102 | 48 | 24 | 3.228346 | 4.015748 | 1.889764 | 0.944882 |
4 cyl piston set 5639 for Singer - 11h.p. 1459cc Eleven
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.5 | 71.4375 | 38.1 | 15.875 | 2.61811 | 2 13/16 | 1 1/2 | 5/8 |
4 cyl piston set 7058 for Albion - 22.5h.p. HL126, J127, JS127, JL127, KN126, KL126, KS127, KN127, KL127, 70/80/90/100/110cwt, PH, PK114, 115, 24/36 seater passenger, Victor, EN212, EN68A, EN215,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
95.25 | 98.425 | 44.45 | 28.575 | 3 3/4 | 3 7/8 | 1 3/4 | 1 1/8 |
6 cyl piston set 7393 for Morris - 25h.p. Overseas C.R 5.75 to 1, C.I
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82 | 99 | 55 | 22 | 3.228346 | 3.897638 | 2.165354 | 0.866142 |
4 cyl piston set 7557 for Commer - 13.95h.p. 15, 20, 25cwt NI Series A Q15, Q25
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
1 cyl piston set 7668 for Rover - 11.9h.p. 1496cc Twelve
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69 | 78.184375 | 40.084375 | 15.875 | 2.716535 | 3 5/64 | 1 37/64 | 5/8 |
4 cyl piston set 7681 for Vauxhall - 10h.p. 1203cc Ten Four, H, C.R. 6.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 75.40625 | 39.6875 | 15.875 | 2 1/2 | 2 31/32 | 1 9/16 | 5/8 |
4 cyl piston set 7691 for Ford - 8h.p. Model Y, 5cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.642 | 59.53125 | 24.60625 | 14.2875 | 2.23 | 2 11/32 | 31/32 | 9/16 |
4 cyl piston set 7751 for Standard - 9h.p. 1287cc Teinmouth Big Nine, C.R. 4.9 to 1, 4 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 76.2 | 38.1 | 15.875 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
4 cyl piston set 7771 for Standard - 9.h.p 1052cc, Little 9, 4 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
60.325 | 69.85 | 34.925 | 15.875 | 2 3/8 | 2 3/4 | 1 3/8 | 5/8 |
4 cyl piston set 7789 for Ford - 10h.p. 10cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 64.29375 | 26.19375 | 17.4625 | 2 1/2 | 2 17/32 | 1 1/32 | 11/16 |
6 cyl piston set 7806 for Vauxhall - 14h.p. 1781cc Light Six ASX
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61.5 | 75.40625 | 39.6875 | 19.05 | 2.42126 | 2 31/32 | 1 9/16 | 3/4 |
6 cyl piston set 7812 for Morris - 14h.p. 1818cc Series II & III Fouteen Six 'Q'
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61.5 | 79.5 | 42.5 | 18 | 2.42126 | 3.129921 | 1.673228 | 0.708661 |
1 cyl piston set 7879 for Alvis - 19.82h.p. 2762cc, 13.22h.p. 1842cc
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73 | 86 | 40 | 20 | 2.874016 | 3.385827 | 1.574803 | 0.787402 |
4 cyl piston set 8027 for Morris - 10h.p. 1140cc Series M, SM Ten Four
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
6 cyl piston set 8109 for Hillman - 16h.p. 2576cc Sixteen
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
67.5 | 93.5 | 51 | 22 | 2.65748 | 3.681102 | 2.007874 | 0.866142 |
4 cyl piston set 8152 for Vauxhall - 12h.p. 1442cc Twelve Four, I, C.R.6.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 93.6625 | 57.94375 | 15.875 | 2.73622 | 3 11/16 | 2 9/32 | 5/8 |
4 cyl piston set 8480 for Austin -
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.769 | 2.235 | 0 | 0 | 0 |
4 cyl piston set 8657 for Morris - LCS, LD, PW 15, 30cwt, 15.95h.p.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 80.9625 | 44.45 | 22 | 3.149606 | 3 3/16 | 1 3/4 | 0.866142 |
6 cyl piston set 8713 for Morris - 25h.p. Overseas C.R 5.75 to 1, Aluminium, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82 | 102.5 | 58 | 22 | 3.228346 | 4.035433 | 2.283465 | 0.866142 |
4 cyl piston set 8743 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 30.95625 | 2 1/2 | 2 3/4 | 1 7/32 |
1 cyl piston set 8817 for Buick - 30.6h.p. 34-40, 34-60, 35-40, 35-60, 37-40 Aluminium version of Cast Iron Piston 4699, 8 cylinder
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
78.58125 | 96.8375 | 57.15 | 20.6375 | 3 3/32 | 3 13/16 | 2 1/4 | 13/16 |
6 cyl piston set 8860 for Bedford - 26.3h.p. WS, WH, WLG, WTH , WTL, WTB, BXC, 26 Seater Passenger 12/30/40/60cwt, Drilled con rod type. Aluminium Piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.1375 | 93.6625 | 47.625 | 25.146 | 3 5/16 | 3 11/16 | 1 7/8 | 0.99 |
4 cyl piston set 8984 for Ford - 8h.p. 933cc Popular Y, short 3 ring piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.642 | 60.325 | 26.19375 | 17.4625 | 2.23 | 2 3/8 | 1 1/32 | 11/16 |
1 cyl piston set 9029 for Buick - 37.81h.p. M.O Type 60, 70, 80, 90 Series, Century, Roadmaster, Limited, 8 cylinder
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 113.50625 | 69.05625 | 22.225 | 3 7/16 | 4 15/32 | 2 23/32 | 7/8 |
6 cyl piston set 9187 for Renault - 1997 cc OHV Frigate, 2 Litre. 17.9h.p. 2383 cc Prairie, 4 cyl. 26.8h.p. 4085 cc, 6 cyl. 35.8h.p. 5448 cc Straight 8
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85 | 95.75 | 52 | 22 | 3.346457 | 3.769685 | 2.047244 | 0.866142 |
6 cyl piston set 9309 for Austin - 26.88h.p. 3459cc CX13, 1 1/2 to 5 ton, 20-26 seater passenger bus C.R. 5.75 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 9744 for Dodge - 23.4h.p. Aluminum version of piston 4983
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.375 | 93.6625 | 50.8 | 21.828125 | 3 1/8 | 3 11/16 | 2 | 55/64 |
6 cyl piston set 9844 for Chrysler - CO 6 cyl, 33.8h.p. Heston, Kingston, CT-CZ, C1-C50, Saratoga, New Yorker, Newport. Aluminium Piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.55 | 98.425 | 50.8 | 21.828125 | 3 1/4 | 3 7/8 | 2 | 55/64 |
6 cyl piston set 10083 for Chrysler - 28.35h.p. 4100cc, SV, C34, C38, C45, C48, C51, Royal, Windsor, Newport, 5 tonner, US Army
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 98.425 | 50.8 | 21.828125 | 3 7/16 | 3 7/8 | 2 | 55/64 |
6 cyl piston set 10170 for Bedford - 27.34h.p. 3519cc, series K, M, O, W, 3/4 to 5 Ton, Tractor 6 to 8 Ton, Cast Iron Piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.725 | 85.725 | 41.275 | 20.6375 | 3 3/8 | 3 3/8 | 1 5/8 | 13/16 |
4 cyl piston set 10453 for Scammell - 10 H.P., MH3, 3 Ton, H'Lex
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 38.89375 | 15.875 | 2 1/2 | 2 3/4 | 1 17/32 | 5/8 |
6 cyl piston set 10567 for Commer - 26.85h.p. 4086cc SV, LNF5, N5, PN4, PNF4, PNF5, CPNF5, Q2, Q3, Q4, Q5, 2-6 1/2 ton, 24 to 26 seater passenger, Commando, Tractor Trailer 6-10ton
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85 | 93 | 51 | 24 | 3.346457 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 11063 for Austin - 7h.p 2 1/2 /5 cwt. Thetis A.B.C. Marine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
55.88 | 46.0375 | 22.225 | 12.7 | 2.2 | 1 13/16 | 7/8 | 1/2 |
4 cyl piston set 11276 for Ford - 30h.p 3622 cc S.V. 3.6 Litre Pilot V8, CR 6.15 to 1 (British Bullet Engine)
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
4 cyl piston set 11583 for Morris - 10h.p. 1292 cc Ten Four, Series II and III
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 74 | 37.5 | 16 | 2 1/2 | 2.913386 | 1.476378 | 0.629921 |
6 cyl piston set 11782 for Perkins - 5560 cc OHV R6, F340, Six 340S, 5.56 Litre, Diesel, CR 17.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
101.6 | 121.8946 | 74.215625 | 36.5125 | 4 | 4.799 | 2 59/64 | 1 7/16 |
4 cyl piston set 12211 for Morris - 24.8h.p. 3519 cc S.V. C, CD, CV, Series 1 1/2 - 5 Ton, 3770 cc S.V., FV, NCV, Series, 3.77 Litre, 5 Ton, H'lex for 5246
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
100 | 107.95 | 57.15 | 26.9875 | 3.937008 | 4 1/4 | 2 1/4 | 1 1/16 |
4 cyl piston set 12417 for Austin - 8h.p. 900 cc Big Seven/New Eight, C.R. 6.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.769 | 63.5 | 31.75 | 12.7 | 2.235 | 2 1/2 | 1 1/4 | 1/2 |
6 cyl piston set 12572 for Austin - 28.8h.p. 3993 cc O.H.V. 4 Lit A125 Sheerline/A135 Princess. CR 6.8 to 1. 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
1 cyl piston set 12629 for Austin - 13.2h.p. 1489cc A50 Cambridge, CR 7.4 to 1, A50/A55 Low Comp CR 7.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
4 cyl piston set 12866 for Austin - 10.65h.p. 1200 cc O.H.V. A40 Cambridge CR 7.2 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65.4685 | 76.99375 | 42.1132 | 17.4625 | 2.5775 | 3 1/32 | 1.658 | 11/16 |
4 cyl piston set 13099 for Rover - 16.6h.p. 2230 cc 75, CR 7.2 to 1, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 105.3846 | 74.422 | 22.225 | 2 7/8 | 4.149 | 2.93 | 7/8 |
4 cyl piston set 13598 for Austin - 1489 cc OHV A50 Cambridge, High Comp CR 8.2 to 1. A50/A55 CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
4 cyl piston set 14022 for Volkswagen - 1192 cc OHV: 1200, 15 cwt. Van, Kombi, Microbus, RWD Air Cooled, Low Comp CR 6.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 80 | 38 | 20 | 3.031496 | 3.149606 | 1.496063 | 0.787402 |
6 cyl piston set 14635 for Mercedes - 3794 cc OHV Majestic, 3.8 litre, CR 7.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.35238 | 87.709375 | 47.0408 | 22.225 | 3.3997 | 3 29/64 | 1.852 | 7/8 |
4 cyl piston set 14978 for Fiat - 633 cc OHV 600, Multipla, RWD.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
60 | 63.25 | 40.75 | 18 | 2.362205 | 2.490157 | 1.604331 | 0.708661 |
4 cyl piston set 16178 for Triumph - 1147 cc OHV Herald 1200, Herald 12/50, Spitfire, Courier 5 cwt. CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.28866 | 74.3458 | 38.4556 | 20.6375 | 2.7279 | 2.927 | 1.514 | 13/16 |
1 cyl piston set 16219 for Hillman - 1494 cc OHV Minx, 1 1/2 litre, CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
78.99908 | 82.6008 | 47.0408 | 22.225 | 3.1102 | 3.252 | 1.852 | 7/8 |
4 cyl piston set 16300 for Opel - 1680 cc 4 Cyl, Olympia Rekord, 1.7 Litre, CR 7.25 to 1, Steel Strut Design
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85 | 95 | 45 | 22 | 3.346457 | 3.740157 | 1.771654 | 0.866142 |
4 cyl piston set 16494 for Renault - 1963-66 1108 cc OHV R8, 1100, Major, Caravelle, 1133, CR 8.5 to 1. 1965-66 R8 1100 Gordini, R8 Automatoc, CR 10.4 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70 | 68 | 40 | 18 | 2.755906 | 2.677165 | 1.574803 | 0.708661 |
1 cyl piston set 16854 for Fiat - 2279 cc OHV 2300, 114 Engine, CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
78 | 85.3 | 42.3 | 22 | 3.070866 | 3.358268 | 1.665354 | 0.866142 |
4 cyl piston set 17271 for Austin - 1275 cc OHV Healey Sprite, MkIV. CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.612 | 69.6849 | 38.0365 | 20.6375 | 2.78 | 2.7435 | 1.4975 | 13/16 |
1 cyl piston set 17308 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
1 cyl piston set 17404 for Volkswagen - 1285 cc OHV 1300 RWD, Air Cooled. CR 7.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 80 | 40 | 22 | 3.031496 | 3.149606 | 1.574803 | 0.866142 |
4 cyl piston set 17483 for Datsun - 1595 cc OHV Bluebird 1600, DR411, Fairlady 1600 SP311 CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.2 | 88 | 45 | 22 | 3.433071 | 3.464567 | 1.771654 | 0.866142 |
4 cyl piston set 17563 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 17569 for Vauxhall - 1599 cc OHC Victor 1600, Viva 1600 SL, Firenza 1600 De Luxe SL, Low Comp, CR 7.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.7 | 81.8388 | 43.8404 | 25.4 | 3.374016 | 3.222 | 1.726 | 1 |
4 cyl piston set 18005 for Austin - 1485 cc OHC Maxi 1500. 1.5 Litre. CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.2 | 74.8284 | 43.0784 | 20.6375 | 3 8.8817841970013E-16/2 | 2.946 | 1.696 | 13/16 |
1 cyl piston set 18236 for Audi - 1760 cc Audi Super 90, 1800-S90 CR 10.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
81.5 | 72.2 | 43.2 | 24 | 3.208661 | 2.84252 | 1.700787 | 0.944882 |
4 cyl piston set 18496 for Hillman - 1498 cc OHV Avenger Grand Luxe, GT CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.12124 | 75.803125 | 44.053125 | 23.8125 | 3.3906 | 2 63/64 | 1 47/64 | 15/16 |
4 cyl piston set 18646 for Ford - 1098 cc OHV Escort 1100, 6/8 cwt Van. Low Comp CR 8 to 1. Uprated 711M Engine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18684 for Ford - 1599 cc OHV Cortina 1600, 1600GT, Capri 1600, 2737E Engine, CR 9 to 1. 1599 cc OHV Capri 1600GT CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18924 for Vauxhall - 1256 cc OHV Viva De Luxe, Firenza De Luxe SL, CR 8.5 to 1. 1975 On, Chevette CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.95 | 70.1294 | 38.227 | 20 | 3.187008 | 2.761 | 1.505 | 0.787402 |
6 cyl piston set 19132 for Ford - 2494 cc OHV Consul, Consul L, Granada, Granada GXL, 2.5 litre V6 CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.346 | 52.1716 | 23.8125 | 3.6869 | 3.99 | 2.054 | 15/16 |
2 cyl piston set 19298 for Ford - 6 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
4 cyl piston set 19377 for Audi - 1760 cc Audi Super 90, 1800-S90 CR 10.6 to 1, 1770 cc OHV Audi 100 LS/S, 1800S Engine, CR 10.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
81.5 | 72.5 | 43.5 | 24 | 3.208661 | 2.854331 | 1.712598 | 0.944882 |
4 cyl piston set 19659 for Nissan - 988 cc A10 Engine. 79-81; Cherry 1.0 L, GL. 70-76; Cherry 100A Deluxe L. 76-79; Chery F11, GLS. 66-70; Sunny 1000
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73 | 67.5 | 32.6 | 17.45 | 2.874016 | 2.65748 | 1.283465 | 0.687008 |
2 cyl piston set 19750 for Volvo - 4 Cyl, 1986 cc OHV 142, 142E, 144, 144E, 145, 142S, 144S, 145S, 144DL, 145DL, 144GL, 1800E, 1800S, 1800ES, B20A, B20F, Engines, CR 8.7 to 1. B20B Engine, CR 9.5...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.89 | 71 | 46 | 22 | 3.499606 | 2.795276 | 1.811024 | 0.866142 |
1 cyl piston set 19970 for Suzuki - 50 cc M15 Sportsman, M15D Sovereign, M12 Supersport, Two Stroke. CR 6.7 to 1. M30 Suzy, Two Stroke, CR 6.3 to 1 AS50, AC50, TS50, F50, A50, Mk II, AP50, A50P, A50K.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
41 | 51.25 | 30.3 | 12 | 1.614173 | 2.017717 | 1.192913 | 0.472441 |
4 cyl piston set 20140 for Triumph - 1296 cc 1300, Herald 13/60, Toledo, Dolomite 1300, CR 8.5 to 1. 1300 TC, Spitfire (Engine RD19477 On), CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.6473 | 66.9671 | 38.4937 | 20.6375 | 2.8995 | 2.6365 | 1.5155 | 13/16 |
4 cyl piston set 20229 for Datsun, Nissan - A14 Engine; Datsun 1396 cc B210, Nissan 1397 cc Sunny 140Y Coupe, GL Estate, Violet 1.4 GL, California 210, Cherry, Pulsar. CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76 | 67.5 | 32.6 | 19 | 2.992126 | 2.65748 | 1.283465 | 0.748031 |
1 cyl piston set 20359 for Suzuki - 739 cc GT500, GT750, J, K, L, M, A, B Two Stroke 3 Cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70 | 79.8 | 36.9 | 18 | 2.755906 | 3.141732 | 1.452756 | 0.708661 |
1 cyl piston set 20551 for Ford - 1292 cc 751M Engine, OHV Cortina 1300, Escort 6-8 Cwt Van, Escort 1300, Popular 1300, Low Comp, CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 20760 for Ford - 1597 cc CVH Engine OHC, Escort 1600L, GL, Ghia, Estate, XR3, CR 9.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.99984 | 20.6375 | 3.1496 | 0 | 0 | 13/16 |
1 cyl piston set 21077 for Austin, Morris - 1993 cc Princess 2000HL/HLS, Morris OHC Ital 2000 HLS Saloon/Estate, Ambassador 2.0 HL/HLS, Montego 2.0 HL/HLS, 'O' Series Engine, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.4423 | 60.2488 | 35.30092 | 20.6375 | 3.3245 | 2.372 | 1.3898 | 13/16 |
1 cyl piston set 21405 for Ford - 957 cc Fiesta L/GL/S, Ghia, Popular, Popular Plus, Fiesta Van Popular, L. CR 8.3/8.5/9.1 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.94 | 65 | 39.2 | 20.63496 | 2.911024 | 2.559055 | 1.543307 | 0.8124 |
1 cyl piston set 23700 for Ford - 1769 cc Sierra 1.8, Sierra L/LX/ GL/ GLX, Sierra Saphire L/LX/GL/GLX, HL1.8H CVH Engine, CR 9.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.94 | 63.059 | 33.1 | 26 | 3.147244 | 2.482638 | 1.30315 | 1.023622 |
1 cyl piston set 234415 for Lister - HA, HB, HW Series, Diesel. CR 15.2 to 1. Water Cooled diameter is 4", Air Cooled is 4.002
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
101.6 | 127 | 73.0885 | 36.5125 | 4 | 5 | 2.8775 | 1 7/16 |
1 cyl piston set 350068 for Ford - 6D 330 cubic inches, D Series, 2703E Vertical, 2708E inclined, Diesel. CR 16.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
99.9998 | 118.11 | 71.0311 | 34.925 | 3.937 | 4.65 | 2.7965 | 1 3/8 |
4 cyl piston set 350232 for Mercedes - 4 cyl 2404 cc, 5 cyl 3005 cc, OM616/617 Engine; 240D/ Lang/TD, 1207D/307D/309D/407D, Unimog 421.600, Industrial Engines, 330D/Lang/TD/GD. CR 21 to 1, Diesel,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
91 | 79.65 | 48.35 | 26 | 3.582677 | 3.135827 | 1.903543 | 1.023622 |
6 cyl piston set 350339 for Perkins - 5800 cc 6.354.4 6 cyl engine, CR 16 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
98.4758 | 120.6754 | 69.8246 | 34.925 | 3.877 | 4.751 | 2.749 | 1 3/8 |
4 cyl piston set 350484 for Austin, Perkins - 1994 cc Prima 80T Engine, Austin Montego 2.0DL, DSL, Turbo. Perkins T4.20 Marine Engine, CR 17 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.4423 | 77.12964 | 48.1203 | 28 | 3.3245 | 3.0366 | 1.8945 | 1.102362 |
1 cyl piston set 515104 for Bedford - 6.243 litre 381 Engine, 60 Series, Direct Injection Diesel, CR 17 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
104.775 | 122.4153 | 75.803125 | 38.1 | 4 1/8 | 4.8195 | 2 63/64 | 1 1/2 |
6 cyl piston set 664426 for Fiat - 1795 cc OHV 1800, 1800B, Engine types 112, 112B. CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
72 | 88.25 | 51 | 22 | 2.834646 | 3.474409 | 2.007874 | 0.866142 |
4 cyl piston set 666532 for Alfa Romeo - Alfasud Ti, Super 1.2/S/SC/Arna 1.2Sl, Piston Pin press fit into con-rod
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 74 | 39 | 21 | 3.149606 | 2.913386 | 1.535433 | 0.826772 |
4 cyl piston set 667909 for Auto Bianci, Fiat - 999 cc 156A2.000 Engine, Fiat Panda 1000 4x4 Fire, Uno 45 Fire. Auto Bianci M204B Engine Y 10 Fire LX, Fire 1.0, Fire 4WD.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70 | 57.4 | 33.9 | 18 | 2.755906 | 2.259843 | 1.334646 | 0.708661 |
1 cyl piston set 11592 JP for Ford - 4 cyl 15.63h.p. 1508 cc OHV Consul, 6cyl 23.44h.p. 2262 cc OHV Zephyr, Zodiac RBP
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.4004 | 82.55 | 47.7012 | 20.6375 | 3.126 | 3 1/4 | 1.878 | 13/16 |
4 cyl piston set 18645 JP for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1 Uprated 711M Engine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set M-0820902 for BMW - 1990 cc, Motor E 21, 80 kW. 320, 320 A, and for USA 320i. CR 8.1 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
89 | 80.2 | 42.2 | 22 | 3.503937 | 3.15748 | 1.661417 | 0.866142 |
