1 cyl piston 12587 for Austin - 8.3h.p. 803cc O.H.V. A30/Seven, CR 7.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57.912 | 65.0875 | 33.3375 | 2.28 | 2 9/16 | 1 5/16 |
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
TR4 (86mm std bore) +.040
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.98916 | 87.3125 | 50.8 | 22.225 | 3.3854 | 3 7/16 | 2 | 7/8 |
Land Rover 2 1/4 Diesel S2 and S3
3.562" Bore Size STD plus oversizes
same as 350001 pistons
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
90.4748 | 100.0252 | 58.5978 | 30.1625 | 3.562 | 3.938 | 2.307 | 1 3/16 |
Standard 12HP
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 78.978125 | 39.290625 | 19.05 | 2.73622 | 3 7/64 | 1 35/64 | 3/4 |
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
6 cyl piston set 2727 for Gardner - 36.5h.p. 70/90cwt 6JO ring below pin. Also Gilford
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
98.425 | 111.125 | 60.325 | 28.575 | 3 7/8 | 4 3/8 | 2 3/8 | 1 1/8 |
4 cyl piston set 3889 for Morris - 19.2h.p. R, TX, 2 ton, Economy model
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88 | 44.45 | 95.25 | 22.225 | 3.464567 | 1 3/4 | 3 3/4 | 7/8 |
4 cyl piston set 4674 for Ford - 10h.p.(Short) 1172cc SV Deluxe, C.E. Prefect,
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 65.0875 | 26.19375 | 17.4625 | 2 1/2 | 2 9/16 | 1 1/32 | 11/16 |
1 cyl piston set 5055 for Fiat - 17h.p. 2516cc 518, Ardita 2000, Type O
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82 | 102 | 48 | 24 | 3.228346 | 4.015748 | 1.889764 | 0.944882 |
4 cyl piston set 5639 for Singer - 11h.p. 1459cc Eleven
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.5 | 71.4375 | 38.1 | 15.875 | 2.61811 | 2 13/16 | 1 1/2 | 5/8 |
4 cyl piston set 7058 for Albion - 22.5h.p. HL126, J127, JS127, JL127, KN126, KL126, KS127, KN127, KL127, 70/80/90/100/110cwt, PH, PK114, 115, 24/36 seater passenger, Victor, EN212, EN68A, EN215,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
95.25 | 98.425 | 44.45 | 28.575 | 3 3/4 | 3 7/8 | 1 3/4 | 1 1/8 |
6 cyl piston set 7393 for Morris - 25h.p. Overseas C.R 5.75 to 1, C.I
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82 | 99 | 55 | 22 | 3.228346 | 3.897638 | 2.165354 | 0.866142 |
4 cyl piston set 7557 for Commer - 13.95h.p. 15, 20, 25cwt NI Series A Q15, Q25
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
1 cyl piston set 7668 for Rover - 11.9h.p. 1496cc Twelve
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69 | 78.184375 | 40.084375 | 15.875 | 2.716535 | 3 5/64 | 1 37/64 | 5/8 |
4 cyl piston set 7681 for Vauxhall - 10h.p. 1203cc Ten Four, H, C.R. 6.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 75.40625 | 39.6875 | 15.875 | 2 1/2 | 2 31/32 | 1 9/16 | 5/8 |
4 cyl piston set 7691 for Ford - 8h.p. Model Y, 5cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.642 | 59.53125 | 24.60625 | 14.2875 | 2.23 | 2 11/32 | 31/32 | 9/16 |
4 cyl piston set 7751 for Standard - 9h.p. 1287cc Teinmouth Big Nine, C.R. 4.9 to 1, 4 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 76.2 | 38.1 | 15.875 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
4 cyl piston set 7771 for Standard - 9.h.p 1052cc, Little 9, 4 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
60.325 | 69.85 | 34.925 | 15.875 | 2 3/8 | 2 3/4 | 1 3/8 | 5/8 |
4 cyl piston set 7789 for Ford - 10h.p. 10cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 64.29375 | 26.19375 | 17.4625 | 2 1/2 | 2 17/32 | 1 1/32 | 11/16 |
6 cyl piston set 7806 for Vauxhall - 14h.p. 1781cc Light Six ASX
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61.5 | 75.40625 | 39.6875 | 19.05 | 2.42126 | 2 31/32 | 1 9/16 | 3/4 |
6 cyl piston set 7812 for Morris - 14h.p. 1818cc Series II & III Fouteen Six 'Q'
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61.5 | 79.5 | 42.5 | 18 | 2.42126 | 3.129921 | 1.673228 | 0.708661 |
1 cyl piston set 7879 for Alvis - 19.82h.p. 2762cc, 13.22h.p. 1842cc
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73 | 86 | 40 | 20 | 2.874016 | 3.385827 | 1.574803 | 0.787402 |
4 cyl piston set 8027 for Morris - 10h.p. 1140cc Series M, SM Ten Four
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
6 cyl piston set 8109 for Hillman - 16h.p. 2576cc Sixteen
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
67.5 | 93.5 | 51 | 22 | 2.65748 | 3.681102 | 2.007874 | 0.866142 |
4 cyl piston set 8152 for Vauxhall - 12h.p. 1442cc Twelve Four, I, C.R.6.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 93.6625 | 57.94375 | 15.875 | 2.73622 | 3 11/16 | 2 9/32 | 5/8 |
4 cyl piston set 8480 for Austin -
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.769 | 2.235 | 0 | 0 | 0 |
4 cyl piston set 8657 for Morris - LCS, LD, PW 15, 30cwt, 15.95h.p.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 80.9625 | 44.45 | 22 | 3.149606 | 3 3/16 | 1 3/4 | 0.866142 |
6 cyl piston set 8713 for Morris - 25h.p. Overseas C.R 5.75 to 1, Aluminium, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82 | 102.5 | 58 | 22 | 3.228346 | 4.035433 | 2.283465 | 0.866142 |
4 cyl piston set 8743 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 30.95625 | 2 1/2 | 2 3/4 | 1 7/32 |
1 cyl piston set 8817 for Buick - 30.6h.p. 34-40, 34-60, 35-40, 35-60, 37-40 Aluminium version of Cast Iron Piston 4699, 8 cylinder
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
78.58125 | 96.8375 | 57.15 | 20.6375 | 3 3/32 | 3 13/16 | 2 1/4 | 13/16 |
6 cyl piston set 8860 for Bedford - 26.3h.p. WS, WH, WLG, WTH , WTL, WTB, BXC, 26 Seater Passenger 12/30/40/60cwt, Drilled con rod type. Aluminium Piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.1375 | 93.6625 | 47.625 | 25.146 | 3 5/16 | 3 11/16 | 1 7/8 | 0.99 |
4 cyl piston set 8984 for Ford - 8h.p. 933cc Popular Y, short 3 ring piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.642 | 60.325 | 26.19375 | 17.4625 | 2.23 | 2 3/8 | 1 1/32 | 11/16 |
1 cyl piston set 9029 for Buick - 37.81h.p. M.O Type 60, 70, 80, 90 Series, Century, Roadmaster, Limited, 8 cylinder
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 113.50625 | 69.05625 | 22.225 | 3 7/16 | 4 15/32 | 2 23/32 | 7/8 |
6 cyl piston set 9187 for Renault - 1997 cc OHV Frigate, 2 Litre. 17.9h.p. 2383 cc Prairie, 4 cyl. 26.8h.p. 4085 cc, 6 cyl. 35.8h.p. 5448 cc Straight 8
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85 | 95.75 | 52 | 22 | 3.346457 | 3.769685 | 2.047244 | 0.866142 |
6 cyl piston set 9744 for Dodge - 23.4h.p. Aluminum version of piston 4983
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.375 | 93.6625 | 50.8 | 21.828125 | 3 1/8 | 3 11/16 | 2 | 55/64 |
6 cyl piston set 10083 for Chrysler - 28.35h.p. 4100cc, SV, C34, C38, C45, C48, C51, Royal, Windsor, Newport, 5 tonner, US Army
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 98.425 | 50.8 | 21.828125 | 3 7/16 | 3 7/8 | 2 | 55/64 |
4 cyl piston set 10453 for Scammell - 10 H.P., MH3, 3 Ton, H'Lex
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 38.89375 | 15.875 | 2 1/2 | 2 3/4 | 1 17/32 | 5/8 |
4 cyl piston set 11063 for Austin - 7h.p 2 1/2 /5 cwt. Thetis A.B.C. Marine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
55.88 | 46.0375 | 22.225 | 12.7 | 2.2 | 1 13/16 | 7/8 | 1/2 |
4 cyl piston set 11583 for Morris - 10h.p. 1292 cc Ten Four, Series II and III
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 74 | 37.5 | 16 | 2 1/2 | 2.913386 | 1.476378 | 0.629921 |
4 cyl piston set 12211 for Morris - 24.8h.p. 3519 cc S.V. C, CD, CV, Series 1 1/2 - 5 Ton, 3770 cc S.V., FV, NCV, Series, 3.77 Litre, 5 Ton, H'lex for 5246
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
100 | 107.95 | 57.15 | 26.9875 | 3.937008 | 4 1/4 | 2 1/4 | 1 1/16 |
6 cyl piston set 12572 for Austin - 28.8h.p. 3993 cc O.H.V. 4 Lit A125 Sheerline/A135 Princess. CR 6.8 to 1. 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
4 cyl piston set 12866 for Austin - 10.65h.p. 1200 cc O.H.V. A40 Cambridge CR 7.2 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65.4685 | 76.99375 | 42.1132 | 17.4625 | 2.5775 | 3 1/32 | 1.658 | 11/16 |
4 cyl piston set 13598 for Austin - 1489 cc OHV A50 Cambridge, High Comp CR 8.2 to 1. A50/A55 CR 8.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
6 cyl piston set 14635 for Mercedes - 3794 cc OHV Majestic, 3.8 litre, CR 7.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.35238 | 87.709375 | 47.0408 | 22.225 | 3.3997 | 3 29/64 | 1.852 | 7/8 |
1 cyl piston set 16219 for Hillman - 1494 cc OHV Minx, 1 1/2 litre, CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
78.99908 | 82.6008 | 47.0408 | 22.225 | 3.1102 | 3.252 | 1.852 | 7/8 |
4 cyl piston set 16494 for Renault - 1963-66 1108 cc OHV R8, 1100, Major, Caravelle, 1133, CR 8.5 to 1. 1965-66 R8 1100 Gordini, R8 Automatoc, CR 10.4 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70 | 68 | 40 | 18 | 2.755906 | 2.677165 | 1.574803 | 0.708661 |
4 cyl piston set 17271 for Austin - 1275 cc OHV Healey Sprite, MkIV. CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.612 | 69.6849 | 38.0365 | 20.6375 | 2.78 | 2.7435 | 1.4975 | 13/16 |
1 cyl piston set 17404 for Volkswagen - 1285 cc OHV 1300 RWD, Air Cooled. CR 7.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 80 | 40 | 22 | 3.031496 | 3.149606 | 1.574803 | 0.866142 |
4 cyl piston set 17563 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 17569 for Vauxhall - 1599 cc OHC Victor 1600, Viva 1600 SL, Firenza 1600 De Luxe SL, Low Comp, CR 7.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.7 | 81.8388 | 43.8404 | 25.4 | 3.374016 | 3.222 | 1.726 | 1 |
2 cyl piston set 18242 for Volvo - 4 Cyl, 1986 cc OHV 142, 142E, 144, 144E, 145, 142S, 144S, 145S, 144DL, 145DL, 144GL, 1800E, 1800S, 1800ES, B20A, B20F, Engines, CR 8.7 to 1. B20B Engine, CR 9.5...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.89 | 71 | 46 | 22 | 3.499606 | 2.795276 | 1.811024 | 0.866142 |
4 cyl piston set 18515 for Austin - 997 cc OHV Seven Cooper CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
62.4205 | 63.2968 | 31.5468 | 15.875 | 2.4575 | 2.492 | 1.242 | 5/8 |
1 cyl piston set 18679 for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1, 2733E Engine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18742 for Triumph - 1709 cc OHC, CR 8.8 to 1 from Engine JBB7510
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
83.48726 | 64.5668 | 34.0868 | 22.225 | 3.2869 | 2.542 | 1.342 | 7/8 |
4 cyl piston set 19064 for Land Rover - 2286 cc OHV Series II, IIA, III, 2 1/4 Litre CR 7 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
90.4748 | 100.0252 | 58.4454 | 25.4 | 3.562 | 3.938 | 2.301 | 1 |
6 cyl piston set 19188 for Rover - 2995 cc 3 litre, Mk I, II and III, CR 8.75 to 1. 2625 cc 100, 2.6 litre CR 7.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.8 | 98.0186 | 66.3702 | 22.225 | 3.062992 | 3.859 | 2.613 | 7/8 |
2 cyl piston set 19299 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
1 cyl piston set 19472 for Chrysler - 1598 cc OHV Avenger 1600 GLS/TC. Low Comp CR 8.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87.33536 | 75.7682 | 44.1198 | 23.8125 | 3.4384 | 2.983 | 1.737 | 15/16 |
2 cyl piston set 19717 for Volvo - 4 cyl 1986 cc OHV: 142 from Engine 393950, 144 from Engine 428000, 145 from Engine 21050, B20A, B20F Engines. CR 8.7 to 1. B20E Engine, CR 10.2 to 1. 6 Cyl, 6...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.9 | 71 | 46 | 24 | 3 1/2 | 2.795276 | 1.811024 | 0.944882 |
1 cyl piston set 19885 for Jaguar - 4235 cc Jaguar OHC MkX, E Type GT, E type 2+2, 420, 420 G, XJ 6 4.2 Litre, XJ 4.2, CR 9 to 11
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
92.075 | 100.8634 | 52.5526 | 22.225 | 3 5/8 | 3.971 | 2.069 | 7/8 |
1 cyl piston set 19970 for Suzuki - 50 cc M15 Sportsman, M15D Sovereign, M12 Supersport, Two Stroke. CR 6.7 to 1. M30 Suzy, Two Stroke, CR 6.3 to 1 AS50, AC50, TS50, F50, A50, Mk II, AP50, A50P, A50K.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
41 | 51.25 | 30.3 | 12 | 1.614173 | 2.017717 | 1.192913 | 0.472441 |
4 cyl piston set 20015 for Toyota - 1897 cc 3R and 3R-B Engines, Crown, Stout, RS30, RS31, RS40, RS46
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88 | 91 | 41 | 24 | 3.464567 | 3.582677 | 1.614173 | 0.944882 |
4 cyl piston set 20140 for Triumph - 1296 cc 1300, Herald 13/60, Toledo, Dolomite 1300, CR 8.5 to 1. 1300 TC, Spitfire (Engine RD19477 On), CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.6473 | 66.9671 | 38.4937 | 20.6375 | 2.8995 | 2.6365 | 1.5155 | 13/16 |
4 cyl piston set 20202 for Opel - 1698 cc 1.7 litre Rekord, Caravan, CR 8.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88 | 87 | 45.1 | 23 | 3.464567 | 3.425197 | 1.775591 | 0.905512 |
4 cyl piston set 20229 for Datsun, Nissan - A14 Engine; Datsun 1396 cc B210, Nissan 1397 cc Sunny 140Y Coupe, GL Estate, Violet 1.4 GL, California 210, Cherry, Pulsar. CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76 | 67.5 | 32.6 | 19 | 2.992126 | 2.65748 | 1.283465 | 0.748031 |
6 cyl piston set 20296 for Rover, Triumph - 2350 cc OHC, 2.3 Litre, CR 9.25 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
81 | 70 | 40.1 | 23.8125 | 3.188976 | 2.755906 | 1.57874 | 15/16 |
1 cyl piston set 20359 for Suzuki - 739 cc GT500, GT750, J, K, L, M, A, B Two Stroke 3 Cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70 | 79.8 | 36.9 | 18 | 2.755906 | 3.141732 | 1.452756 | 0.708661 |
1 cyl piston set 20397 for Austin, Morris - 1098 cc Austin A40 MkII 1100 OHV/Allegro 1100 De Luxe, Morris 1100/Minor 1000 OHV. 'A' Series Engine CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 58.0517 | 30.3276 | 15.86738 | 2.542 | 2.2855 | 1.194 | 0.6247 |
4 cyl piston set 20551 for Ford - 1291 cc 751M Engine, OHV Cortina 1300, Escort 6-8 Cwt Van, Escort 1300, Popular 1300, Low Comp, CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20611 for Ford - 1600 cc OHV Fiesta USA Version
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 81.71688 | 42.11828 | 20.6375 | 3.1884 | 3.2172 | 1.6582 | 13/16 |
4 cyl piston set 20760 for Ford - 1597 cc CVH Engine OHC, Escort 1600L, GL, Ghia, Estate, XR3, CR 9.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.99984 | 20.6375 | 3.1496 | 0 | 0 | 13/16 |
4 cyl piston set 20841 for Lancia - 1298 cc 813.302, 818.303 Engines, 85/87/89/92h.p. Fulvia Coupe Rallye 1.3, Fulvia Sport 1.3, Zagato, Fulvia GTF, Fulvia Berlina, Fulvia Coupe 1.3 S, Monte...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 80.9 | 45.9 | 22 | 3.031496 | 3.185039 | 1.807087 | 0.866142 |
4 cyl piston set 21077 for Austin, Morris - 1993 cc Princess 2000HL/HLS, Morris OHC Ital 2000 HLS Saloon/Estate, Ambassador 2.0 HL/HLS, Montego 2.0 HL/HLS, 'O' Series Engine, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.4423 | 60.2488 | 35.30092 | 20.6375 | 3.3245 | 2.372 | 1.3898 | 13/16 |
1 cyl piston set 21135 for Suzuki - 123 cc 1 Cyl TS125 C, C2, ERN, ERT, ERZ
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56 | 66 | 32.5 | 14 | 2.204724 | 2.598425 | 1.279528 | 0.551181 |
1 cyl piston set 21405 for Ford - 957 cc Fiesta L/GL/S, Ghia, Popular, Popular Plus, Fiesta Van Popular, L. CR 8.3/8.5/9.1 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.94 | 65 | 39.2 | 20.63496 | 2.911024 | 2.559055 | 1.543307 | 0.8124 |
1 cyl piston set 21776 for Suzuki - 970 cc F10A Engine, OHC Jimny SJ410/Q/V, 4WD, 110S40FK, 1000SJ40VC CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65.5 | 2.57874 | 0 | 0 | 0 |
1 cyl piston set 23875 for Land Rover - 3950 cc 3.9L Efi Engine, Discovery, Range Rover Vogue SE, 8 Cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
94 | 77.1 | 47.295 | 22.225 | 3.700787 | 3.035433 | 1.862008 | 7/8 |
1 cyl piston set 91522 for Perkins - 3 Cyl 2.36 litre P3, 144. 4 Cyl 3.15 Litre, PA, PB, P4, 4.192. 6 Cyl 4.73 Litre PF, PG, P6, 6.288. Diesel, H'lex for 7650
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.9254 | 107.8484 | 57.0484 | 31.75 | 3.501 | 4.246 | 2.246 | 1 1/4 |
1 cyl piston set 247105 for Perkins - 6.354 ,5.8 Litre, Direct Injection Diesel, CR 16 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
98.4758 | 120.65 | 69.85 | 34.925 | 3.877 | 4 3/4 | 2 3/4 | 1 3/8 |
1 cyl piston set 350023 for Lister - HRA, HRW, Series, Diesel. Water cooled Diameter is 4 1/4, Air Cooled is 4.252
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
107.95 | 127 | 73.0885 | 39.6875 | 4 1/4 | 5 | 2.8775 | 1 9/16 |
6 cyl piston set 350076 for Perkins - T6.354.3, 5.8 Litre, Turbocharged Direct Injection Diesel. CR 16 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
98.4758 | 107.90936 | 69.83476 | 38.1 | 3.877 | 4.2484 | 2.7494 | 1 1/2 |
4 cyl piston set 350165 for Perkins - 4.154, 2.523 litre, Indirect Injection Diesel, CR 21.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.9254 | 115.6462 | 60.198 | 31.75 | 3.501 | 4.553 | 2.37 | 1 1/4 |
4 cyl piston set 350235 for Mercedes - 1988 cc OM615.913/915/937 Engines, 200D, L206D, L306D. Diesel. CR 21 to 1, Steel Strut Design.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
87 | 91.36 | 52.9 | 26 | 3.425197 | 3.59685 | 2.082677 | 1.023622 |
1 cyl piston set 350263 for Land Rover - 2 1/4 Litre Series II and III, Diesel. CR 23 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
90.4748 | 100.0252 | 58.5978 | 30.1625 | 3.562 | 3.938 | 2.307 | 1 3/16 |
1 cyl piston set 350341 for Lister - HR, HRW Series, 2/3 Cyls, Diesel. Water cooled Diameter is 4 1/4, Air Cooled is 4.252
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
107.95 | 127 | 73.0758 | 39.6875 | 4 1/4 | 5 | 2.877 | 1 9/16 |
1 cyl piston set 350382 for Ford - 3294 cc 201 cu.in, 3 cyl, Series 6Y, Major 4000 Tractor, Series 7A, 4600. Also BSD333H/BSD444 Engine, Direct injection 4610, 4610SU Tractors, 6610, 6710...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
111.77778 | 127 | 68.1228 | 38.1 | 4.4007 | 5 | 2.682 | 1 1/2 |
4 cyl piston set 350977 for Opel, Vauxhall - 1700 cc Astra OHC Turbocharged Intercooled. CR 23 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
82.5 | 72.95 | 44.95 | 26 | 3.248031 | 2.872047 | 1.769685 | 1.023622 |
1 cyl piston set 517803 for Ford - 4 Cyl, 4D 240 cubic inches , D Series, 2701E Vertical, 2706E Inclined. 6 Cyl 6D 360 cubic inches, D series, 2704E Vertical, 2709E Inclined.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
104.775 | 118.26875 | 71.040625 | 34.925 | 4 1/8 | 4 21/32 | 2 51/64 | 1 3/8 |
1 cyl piston set 583206 for David Brown - 3 cyl 2695 cc 880, 885. 4 cyl 3594 cc 995/996/1200/1210/1212. Direct Injection Diesel. CR 17 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
6 cyl piston set 664426 for Fiat - 1795 cc OHV 1800, 1800B, Engine types 112, 112B. CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
72 | 88.25 | 51 | 22 | 2.834646 | 3.474409 | 2.007874 | 0.866142 |
1 cyl piston set 665872 for Fiat - 125 Berlina, Engine type 125A CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 83.7 | 44.2 | 22 | 3.149606 | 3.295276 | 1.740157 | 0.866142 |
1 cyl piston set 666709 for Fiat - 1585 cc 131
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84 | 77.95 | 38.45 | 22 | 3.307087 | 3.068898 | 1.51378 | 0.866142 |
4 cyl piston set 667234 for Fiat - 1301 cc 131B.000 OHC, 131 Supermirafiori, CR 8.9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.05 | 82.95 | 38.45 | 22 | 2.994094 | 3.265748 | 1.51378 | 0.866142 |
4 cyl piston set 674110 for Simca - 1290 cc OHV Aronde, Rush Engine, CR 7.5 to 1. Rush Super engine CR 8.5 to 1. 1300, 1301 CR 8.3 to 1. 1301GL, 1301LS CR 8.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74 | 78.5 | 42 | 22 | 2.913386 | 3.090551 | 1.653543 | 0.866142 |
1 cyl piston set 900033 for Ruston Hornsby - YB Series, Direct injection Diesel, RBP, Air and Water cooled available, 1/2 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
88.9 | 123.825 | 73.0758 | 34.925 | 3 1/2 | 4 7/8 | 2.877 | 1 3/8 |
4 cyl piston set 11920 JP for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
4 cyl piston set 132.14.00 for Peugeot - 2498 cc XD3, XD3P Engines, 505 GRD/GLD/SRD, Break, Familiale, J9 Pick-Up, CR 23 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
94 | 96.42 | 53.92 | 30 | 3.700787 | 3.796063 | 2.122835 | 1.181102 |
