6 cyl piston set 8237 for Austin - 16h.p. Engine fitted to 12-6 chassis 1934-38, 16h.p. 1711cc Fourteen, Goodwood 1937-40, C.R 6.4 to 1, Tornado Marine Engine Model. 6 Cylinder
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65.5 | 72.23125 | 33.3375 | 2.57874 | 2 27/32 | 1 5/16 |
BMC 2520cc petrol / BMC EA
FX4
3.404" bore
C.R. 7.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.9376 | 98.425 | 47.625 | 22.225 | 3.344 | 3 7/8 | 1 7/8 | 7/8 |
4 cyl piston set 2254 for Standard - 4 Cyl, 10h.p. and Big 9. 6 Cyl, 15h.p., Teignmouth Saloon
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 76.2 | 38.1 | 15.875 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
1 cyl piston set 3766 for Morris - 17.9h.p. D, 4 cyl, 26.8h.p. Y, Viceroy 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85 | 95.25 | 44.45 | 22.225 | 3.346457 | 3 3/4 | 1 3/4 | 7/8 |
4 cyl piston set 4376 for Renault - 12h.p. 1463cc Airline, YN2 Aluminium version of piston 4831
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70 | 78.5 | 43.5 | 18 | 2.755906 | 3.090551 | 1.712598 | 0.708661 |
6 cyl piston set 5039 for Bedford - 20h.p. BYC, 12cwts C.R. 5.625 to 1. Cast Iron Piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 77.7875 | 41.275 | 22.225 | 2 7/8 | 3 1/16 | 1 5/8 | 7/8 |
6 cyl piston set 5323 for REO - 23.5h.p. Flying Cloud 5
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79.375 | 101.6 | 56.753125 | 25.003125 | 3 1/8 | 4 | 2 15/64 | 63/64 |
4 cyl piston set 7017 for Ford -
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.04 | 2.6 | 0 | 0 | 0 |
4 cyl piston set 7229 for Ford -
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.7 | 2.232283 | 0 | 0 | 0 |
4 cyl piston set 7557 for Commer - 13.95h.p. 15, 20, 25cwt NI Series A Q15, Q25
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
1 cyl piston set 7638 for Lister - 5/1, 10/2 Diesel
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
114.3 | 137.16 | 64.77 | 31.75 | 4 1/2 | 5.4 | 2.55 | 1 1/4 |
4 cyl piston set 7681 for Vauxhall - 10h.p. 1203cc Ten Four, H, C.R. 6.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 75.40625 | 39.6875 | 15.875 | 2 1/2 | 2 31/32 | 1 9/16 | 5/8 |
4 cyl piston set 7684 for Ford - 30h.p. V8 Flat Top 15, 40, 60, 80cwt, Passenger 20 seater, Sussex and Surrey, Rigid Six, B, BB, 46, 50, 51, 67, 1/2 to 1 1/2 ton C.R. 6.12 to 1. Aluminium.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7875 | 75.40625 | 38.89375 | 19.05 | 3 1/16 | 2 31/32 | 1 17/32 | 3/4 |
4 cyl piston set 7751 for Standard - 9h.p. 1287cc Teinmouth Big Nine, C.R. 4.9 to 1, 4 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 76.2 | 38.1 | 15.875 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
1 cyl piston set 7763 for Morris - 11.9h.p. 1550cc SV Twelve Four S11 1937 to 37, 11.9h.p. OHV Twelve Four, 'T' Series III 1938 to 41
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 80.5 | 42.5 | 18 | 2.73622 | 3.169291 | 1.673228 | 0.708661 |
4 cyl piston set 7789 for Ford - 10h.p. 10cwt
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 64.29375 | 26.19375 | 17.4625 | 2 1/2 | 2 17/32 | 1 1/32 | 11/16 |
8 cyl piston set 7798 for Ford - 22h.p. V8 (Export 60h.p.) 73, 82C, 922C, )22C, 92D, 02D, 82Y, 92Y, 02Y, 75, Thames 1/2 to 6 ton C.R 6.6 to 1. Aluminium verson of piston 9036
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
66.04 | 71.040625 | 36.115625 | 17.4625 | 2.6 | 2 51/64 | 1 27/64 | 11/16 |
6 cyl piston set 7812 for Morris - 14h.p. 1818cc Series II & III Fouteen Six 'Q'
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61.5 | 79.5 | 42.5 | 18 | 2.42126 | 3.129921 | 1.673228 | 0.708661 |
4 cyl piston set 7816 for Standard - 9h.p. 1131cc Flying Nine C.R.6.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
60 | 73.025 | 38.1 | 15.875 | 2.362205 | 2 7/8 | 1 1/2 | 5/8 |
4 cyl piston set 8027 for Morris - 10h.p. 1140cc Series M, SM Ten Four
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
6 cyl piston set 8091 for Rover - 13.8h.p. 1577cc OHV Fourteen
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61 | 71.4375 | 33.3375 | 15.875 | 2.401575 | 2 13/16 | 1 5/16 | 5/8 |
4 cyl piston set 8152 for Vauxhall - 12h.p. 1442cc Twelve Four, I, C.R.6.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 93.6625 | 57.94375 | 15.875 | 2.73622 | 3 11/16 | 2 9/32 | 5/8 |
6 cyl piston set 8243 for Vauxhall - 14.6h.p. 1781cc fourteen Six from Engine No. DX 520001, Drilled con-rod type
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
61.5 | 75.40625 | 39.6875 | 19.05 | 2.42126 | 2 31/32 | 1 9/16 | 3/4 |
4 cyl piston set 8612 for Jaguar - Standard
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 2 7/8 | 0 | 0 | 0 |
6 cyl piston set 8676 for Chrysler - 27.3h.p. Croydon, Kingston, Richmond, CA, CB, Airstream, Royal 6, C6, C7, C16, C18, C22, C25, C25S, C28S, C28W
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.725 | 98.425 | 50.8 | 21.828125 | 3 3/8 | 3 7/8 | 2 | 55/64 |
4 cyl piston set 8743 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
6 cyl piston set 8781 for Sunbeam - 23.8h.p. 3318 cc 25, Sports 25
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 77.25 | 36 | 22 | 3.149606 | 3.041339 | 1.417323 | 0.866142 |
6 cyl piston set 8860 for Bedford - 26.3h.p. WS, WH, WLG, WTH , WTL, WTB, BXC, 26 Seater Passenger 12/30/40/60cwt, Drilled con rod type. Aluminium Piston
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
84.1375 | 93.6625 | 47.625 | 25.146 | 3 5/16 | 3 11/16 | 1 7/8 | 0.99 |
6 cyl piston set 8920 for Gardner - L2, LW, HLW, Series Diesel C. R. 13 to 1 Valve recess on GP centre line, Circlip pin
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
107.95 | 165.1 | 111.125 | 41.275 | 4 1/4 | 6 1/2 | 4 3/8 | 1 5/8 |
6 cyl piston set 9025 for Humber - 23.8h.p. Snipe, Pullman
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 92.25 | 51 | 24 | 3.149606 | 3.63189 | 2.007874 | 0.944882 |
4 cyl piston set 9138 for Morris - Ambulance 14h.p.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 80.5 | 42.5 | 18 | 2.952756 | 3.169291 | 1.673228 | 0.708661 |
6 cyl piston set 9309 for Austin - 26.88h.p. 3459cc CX13, 1 1/2 to 5 ton, 20-26 seater passenger bus C.R. 5.75 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.09 | 93.6625 | 47.625 | 22.225 | 3.35 | 3 11/16 | 1 7/8 | 7/8 |
4 cyl piston set 9533 for Coventry Climax - 7.76h.p. Fire Pump Type FSM, C.R. 6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56 | 69.85 | 41.275 | 15.875 | 2.204724 | 2 3/4 | 1 5/8 | 5/8 |
4 cyl piston set 9825 for Renault - 13.9h.p. KZ3-8, 4 Cyl, Aluminium version.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 91.5 | 51 | 18 | 2.952756 | 3.602362 | 2.007874 | 0.708661 |
4 cyl piston set 10014 for Humber - 12h.p. 1669cc SV Twelve
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.5 | 92.67 | 51 | 22 | 2.73622 | 3.648425 | 2.007874 | 0.866142 |
1 cyl piston set 10165 for Ford - 10 h.p. 1172cc SV Prefect, Export Anglia, 10cwt. Heplex version of 8743
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
1 cyl piston set 10294 for Villiers - 98 cc Mark 10
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
50 | 50.00625 | 24.60625 | 15.5448 | 1.968504 | 1 31/32 | 31/32 | 0.612 |
4 cyl piston set 10566 for Morris - Oxford Taxi 1803cc OHV, 13.93h.p.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75 | 2.952756 | 0 | 0 | 0 |
1 cyl piston set 10715 for Leyland - 3400 cc OHV 344 Tractor, CR 17.5 to 1, 4 cyl. 5103 cc OHV, 5.1 Litre, Redline Laird, Redline Terrier, CR 16.5 to 1, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
95 | 120.8024 | 70.2564 | 34.925 | 3.740157 | 4.756 | 2.766 | 1 3/8 |
4 cyl piston set 11276 for Ford - 30h.p 3622 cc S.V. 3.6 Litre Pilot V8, CR 6.15 to 1 (British Bullet Engine)
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7875 | 81.75625 | 45.24375 | 19.05 | 3 1/16 | 3 7/32 | 1 25/32 | 3/4 |
4 cyl piston set 11542 for Continental - N62 (For Gasoline to 5000ft, Kerosene/Distillate above)
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
60.325 | 57.15 | 31.75 | 13.7922 | 2 3/8 | 2 1/4 | 1 1/4 | 0.543 |
1 cyl piston set 11920 for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
1 cyl piston set 12417 for Austin - 8h.p. 900 cc Big Seven/New Eight, C.R. 6.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
56.769 | 63.5 | 31.75 | 12.7 | 2.235 | 2 1/2 | 1 1/4 | 1/2 |
4 cyl piston set 12541 for Austin - 10.6h.p. 1200 cc O.H.V. A40 Sports/A40 Somerset. CR 7.2 to 1. (RBP)
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65.4812 | 75.184 | 40.259 | 15.875 | 2.578 | 2.96 | 1.585 | 5/8 |
4 cyl piston set 12621 for Austin - 803 cc OHV A30, Seven, High Comp CR 7.9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
57.912 | 65.0875 | 33.3375 | 14.2875 | 2.28 | 2 9/16 | 1 5/16 | 9/16 |
4 cyl piston set 12682 for Hillman - 1390 cc OHV Minx, Mark VIII, Husky Series I and II, CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.2 | 82.55 | 46.99 | 22.225 | 3 8.8817841970013E-16/2 | 3 1/4 | 1.85 | 7/8 |
6 cyl piston set 13099 for Rover - 16.6h.p. 2230 cc 75, CR 7.2 to 1, 6 cyl
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 105.3846 | 74.422 | 22.225 | 2 7/8 | 4.149 | 2.93 | 7/8 |
6 cyl piston set 13517 for Rover - 19.8h.p. 2638 cc 90, 2.6 Litre, CR 6.73 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
73.025 | 94.488 | 62.738 | 17.4625 | 2 7/8 | 3.72 | 2.47 | 11/16 |
4 cyl piston set 14022 for Volkswagen - 1192 cc OHV: 1200, 15 cwt. Van, Kombi, Microbus, RWD Air Cooled, Low Comp CR 6.6 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 80 | 38 | 20 | 3.031496 | 3.149606 | 1.496063 | 0.787402 |
4 cyl piston set 14332 for Dodge - D55-1 Coronet, D55-2 Royal, D55-3 Royal Lancer, Custom Royal, D63-1 Coronet, D55-3 Royal Lancer, Custom Royal, D61-1 Crusader, D61-2 Regent, D61-3 Mayfair, from...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
92.075 | 81.75625 | 42.8625 | 21.8186 | 3 5/8 | 3 7/32 | 1 11/16 | 0.859 |
4 cyl piston set 14978 for Fiat - 633 cc OHV 600, Multipla, RWD.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
60 | 63.25 | 40.75 | 18 | 2.362205 | 2.490157 | 1.604331 | 0.708661 |
4 cyl piston set 15635 for Volkswagen - 1192 cc OHV 15 cwt. Van, Kombi, Multibus, RWD, Air Cooled CR 7 to 1, 1200 RWD Air Cooled 113 Motor, CR 7 to 1.
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 79 | 39 | 20 | 3.031496 | 3.110236 | 1.535433 | 0.787402 |
4 cyl piston set 16178 for Triumph - 1147 cc OHV Herald 1200, Herald 12/50, Spitfire, Courier 5 cwt. CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
69.28866 | 74.3458 | 38.4556 | 20.6375 | 2.7279 | 2.927 | 1.514 | 13/16 |
4 cyl piston set 16204 for Austin - 1098 cc OHV A40 MkII, 1100 Low Comp CR 7.5 to 1/ A35 6 Cwt Van, 7.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
64.5668 | 58.1152 | 30.3276 | 15.875 | 2.542 | 2.288 | 1.194 | 5/8 |
4 cyl piston set 16236 for Volkswagen - 1493 cc OHV 1500N, RWD Air Cooled, 311 motor CR 7.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
83 | 83 | 40 | 22 | 3.267717 | 3.267717 | 1.574803 | 0.866142 |
4 cyl piston set 16412 for Rover - 1997 cc 60, 2 Litre, CR 6.9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.8 | 93.2942 | 61.5442 | 3.062992 | 3.673 | 2.423 |
4 cyl piston set 16494 for Renault - 1963-66 1108 cc OHV R8, 1100, Major, Caravelle, 1133, CR 8.5 to 1. 1965-66 R8 1100 Gordini, R8 Automatoc, CR 10.4 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70 | 68 | 40 | 18 | 2.755906 | 2.677165 | 1.574803 | 0.708661 |
4 cyl piston set 17215 for Vauxhall - 1159 cc OHV Viva De-Luxe, SL, CR 8.5 to 1 (Low Comp 7.3 to 1). 90 De Luxe, 90 SL, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77.7494 | 75.565 | 37.6174 | 20 | 3.061 | 2.975 | 1.481 | 0.787402 |
4 cyl piston set 17271 for Austin - 1275 cc OHV Healey Sprite, MkIV. CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
70.612 | 69.6849 | 38.0365 | 20.6375 | 2.78 | 2.7435 | 1.4975 | 13/16 |
4 cyl piston set 17357 for Austin, Morris - 1798cc OHV 1800 CR 8.2 to 1, RBP
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.2513 | 76.99375 | 42.06875 | 20.6375 | 3.1595 | 3 1/32 | 1 21/32 | 13/16 |
1 cyl piston set 17404 for Volkswagen - 1285 cc OHV 1300 RWD, Air Cooled. CR 7.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 80 | 40 | 22 | 3.031496 | 3.149606 | 1.574803 | 0.866142 |
4 cyl piston set 17525 for Austin, MG, Wolsely - 1798cc OHV 1800 - CR 8.4 to 1/1800 MkII CR 9 to 1/1800s MkII CR 9.5 to 1, MGB. Circlip Type
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.2513 | 61.11875 | 42.06875 | 20.6375 | 3.1595 | 2 13/32 | 1 21/32 | 13/16 |
4 cyl piston set 17563 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 17753 for Triumph - 2498 cc OHV TR5PI, TR6PI, 2.5PI, CR 9.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74.6887 | 61.976 | 28.971875 | 20.6375 | 2.9405 | 2.44 | 1 9/64 | 13/16 |
4 cyl piston set 18005 for Austin - 1485 cc OHC Maxi 1500. 1.5 Litre. CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.2 | 74.8284 | 43.0784 | 20.6375 | 3 8.8817841970013E-16/2 | 2.946 | 1.696 | 13/16 |
4 cyl piston set 18400 for Ford - 997 cc OHV Anglia, Thames 5-7 Cwt, 105E Engine, Perfect 107E Engine, CR 8.9 to 1, Thames 5-7 Cwt 307E Engine CR 7.5 to 1. 1198 cc OHV Anglia Super, Cortina,...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.9498 | 77.216 | 38.9636 | 20.6375 | 3.187 | 3.04 | 1.534 | 13/16 |
4 cyl piston set 18496 for Hillman - 1498 cc OHV Avenger Grand Luxe, GT CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.12124 | 75.803125 | 44.053125 | 23.8125 | 3.3906 | 2 63/64 | 1 47/64 | 15/16 |
4 cyl piston set 18598 for Vauxhall - 3294 cc OHV Velox, Cresta, Viscount, Ventora, Victor 3300, CR 8.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
92.075 | 77.978 | 44.5008 | 22.0091 | 3 5/8 | 3.07 | 1.752 | 0.8665 |
4 cyl piston set 18646 for Ford - 1098 cc OHV Escort 1100, 6/8 cwt Van. Low Comp CR 8 to 1. Uprated 711M Engine
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 18682 for Ford - 1298 cc OHV Cortina 1300, Escort 1300, Capri 1300, 8 Cwt Van, 2735E Engine, Low Comp CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18684 for Ford - 1599 cc OHV Cortina 1600, 1600GT, Capri 1600, 2737E Engine, CR 9 to 1. 1599 cc OHV Capri 1600GT CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18762 for Hillman - 1592 cc OHV Minx 1600, Super Minx Low Comp CR 7 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
81.53908 | 82.55 | 46.99 | 23.8125 | 3.2102 | 3 1/4 | 1.85 | 15/16 |
4 cyl piston set 18924 for Vauxhall - 1256 cc OHV Viva De Luxe, Firenza De Luxe SL, CR 8.5 to 1. 1975 On, Chevette CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.95 | 70.1294 | 38.227 | 20 | 3.187008 | 2.761 | 1.505 | 0.787402 |
1 cyl piston set 19114 for Vauxhall - 1759 cc Bedford CF 1800 14-18 cwt Vans OHC. Vauxhall OHC Victor 1800 De luxe, Viva 1800 De Luxe SL, Firenza 1800 De Luxe SL, Magnum 1800, Low Comp, CR 7.3 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85.6996 | 77.216 | 39.2176 | 25.4 | 3.374 | 3.04 | 1.544 | 1 |
4 cyl piston set 19132 for Ford - 2494 cc OHV Consul, Consul L, Granada, Granada GXL, 2.5 litre V6 CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 101.346 | 52.1716 | 23.8125 | 3.6869 | 3.99 | 2.054 | 15/16 |
4 cyl piston set 19275 for Austin - 1748 cc OHC Maxi 1750HL, CR 9.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.2 | 63.6905 | 35.84194 | 20.6375 | 3 8.8817841970013E-16/2 | 2.5075 | 1.4111 | 13/16 |
1 cyl piston set 19300 for Ford - 1966 onwards 4 cyl 1996 cc OHV Corsair GT, Zephyr 4 MkIV, Corsair 2000, 2000E, Capri, 2000GT, 1972 onwards OHV Consul, Consul L, 2 litre V4 CR 10 to 1. 6 cyl 2994...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.64726 | 94.996 | 46.1391 | 23.8125 | 3.6869 | 3.74 | 1.8165 | 15/16 |
4 cyl piston set 19569 for Volkswagen - 1285 cc 1302, 1303. CR 7.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
77 | 82.8 | 42.8 | 22 | 3.031496 | 3.259843 | 1.685039 | 0.866142 |
1 cyl piston set 19737 for Daihatsu - 1588cc Charmant 1600, CR 9.4 to 1
85mm bore 39.1mm compression pin height 90.75mm total height
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
85 | 90.75 | 39.1 | 22.01 | 3.346457 | 3.572835 | 1.53937 | 0.866535 |
4 cyl piston set 19915 for Ford - 1599 cc OHV Transit 75/90/115, 751M Engine, Low Comp CR 8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20128 for Land Rover, Rover - 2286 cc OHV Series II, IIA, III, 2 1/4 Litre, Rover 80, CR 7 to 1, Optional 4 Ring design
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
90.4748 | 99.9236 | 58.5216 | 25.4 | 3.562 | 3.934 | 2.304 | 1 |
4 cyl piston set 20216 for Honda - 1600 cc EF Engine, OHC Accord, CR 8.4 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
74 | 57.5 | 27.6 | 17 | 2.913386 | 2.26378 | 1.086614 | 0.669291 |
1 cyl piston set 20319 for Ford - 2792 cc 2.8 Litre, V6, Injection and Carburettor Types, Granada LS/GL/Ghia, CR 9.2 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
93.01 | 74.53 | 40.13 | 24 | 3.661811 | 2.934252 | 1.579921 | 0.944882 |
4 cyl piston set 20468 for Opel - 1196 cc Kadett C/L-12/Coupe/Coupe Hatchback, Caravan/City/Aero/Ascona 1.2/L/Berlina, CR 7.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
79 | 76 | 38.1 | 20 | 3.110236 | 2.992126 | 1 1/2 | 0.787402 |
6 cyl piston set 20615 for Jaguar - 3781 cc, Mk IX 3.8, Mk X 3.8, XK150, CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.99 | 105.385 | 41.885 | 22.23008 | 3.424803 | 4.149016 | 1.649016 | 0.8752 |
4 cyl piston set 21069 for Mitsubishi - 1410 cc G12B, 4G12 Engine, OHC Mirage 1400, GL/GLX/GLS, Lancer 1400 EL/GL/SL, Celeste 1400 SR/GL/GSL Coupe. CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
76.5 | 58 | 28.9 | 18 | 3.011811 | 2.283465 | 1.137795 | 0.708661 |
4 cyl piston set 21227 for Honda - 1335 cc 4 cyl. Civic 1300, EN/EJ Engines, CR 8.4 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
72 | 65.9 | 27.55 | 17 | 2.834646 | 2.594488 | 1.084646 | 0.669291 |
4 cyl piston set 21974 for Volkswagen - 1043 cc OHC Derby C, CL, GL, golf, C, CL, GL, Polo C, CL, GL. CR 9.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
75.01 | 73.4 | 49.4 | 20 | 2.95315 | 2.889764 | 1.944882 | 0.787402 |
1 cyl piston set 169405 for Perkins - 5560 cc OHV R6, F340, Six 340S, 5.56 Litre, Diesel, CR 17.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
101.6 | 121.7676 | 74.2696 | 36.5125 | 4 | 4.794 | 2.924 | 1 7/16 |
1 cyl piston set 350041 for Lister - ST Series, Air Cooled Diesel
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
95.25 | 103.1875 | 65.151 | 33.3375 | 3 3/4 | 4 1/16 | 2.565 | 1 5/16 |
4 cyl piston set 350201 for Ford - 3294 cc 201 cu.in, 3 cyl, Series 6Y, Major 4000 Tractor, Series 7A, 4600
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
111.77778 | 127 | 68.1228 | 38.1 | 4.4007 | 5 | 2.682 | 1 1/2 |
1 cyl piston set 350303 for Ford - 4196 cc 256 Cu.in 4 cyl Turbocharged, Series 6Y, 7000, Series 7A, 7600, 7700, Dexta Tractor, CR 16.5 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
111.77778 | 129.2606 | 70.3834 | 41.275 | 4.4007 | 5.089 | 2.771 | 1 5/8 |
1 cyl piston set 350392 for Leyland - 0.401 and 0.402 Engines, 6540 cc Bear, Chieftains, Clydesdales, Guy Big J4, Reiver, Super Comet, Super Clydesdale, Super Reiver, Super Reiver 20, Tractor...
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
107.188 | 145.5928 | 82.1436 | 41.275 | 4.22 | 5.732 | 3.234 | 1 5/8 |
1 cyl piston set 428705 for Ford - 4 cyl, 3610 cc 4D Thames Trader, 1 1/2-5 ton, Major, Power Major, Super Major Tractor. 6 cyl 5416 cc 6D Thames Trader 4-7 Ton, 590E, 592E Engine, CR 16 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
99.9998 | 118.11 | 70.993 | 34.925 | 3.937 | 4.65 | 2.795 | 1 3/8 |
4 cyl piston set 665872 for Fiat - 125 Berlina, Engine type 125A CR 8.8 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
80 | 83.7 | 44.2 | 22 | 3.149606 | 3.295276 | 1.740157 | 0.866142 |
4 cyl piston set 667432 for Fiat - 903 cc 100 GL Engine, 127 Special, L/C/CL, 900T Pulmino, Fiorino, Panda 45. CR 9 to 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
65 | 61.25 | 30.75 | 20 | 2.559055 | 2.411417 | 1.21063 | 0.787402 |
6 cyl piston set 18393 JP for Jaguar - 3781 cc OHC Mk IX, 3.8 Lit, XK150 3.8, Mk X, S type, CR 8 TO 1
Metric (mm) | English (Inches) | ||||||
---|---|---|---|---|---|---|---|
Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
86.99 | 100.8634 | 52.5526 | 22.225 | 3.424803 | 3.971 | 2.069 | 7/8 |
