| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
Land Rover 2 1/4 Diesel S2 and S3
3.562" Bore Size STD plus oversizes
same as 350001 pistons
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4748 | 100.0252 | 58.5978 | 30.1625 | 3.562 | 3.938 | 2.307 | 1 3/16 |
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
6 cyl piston set 2727 for Gardner - 36.5h.p. 70/90cwt 6JO ring below pin. Also Gilford
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98.425 | 111.125 | 60.325 | 28.575 | 3 7/8 | 4 3/8 | 2 3/8 | 1 1/8 |
4 cyl piston set 3889 for Morris - 19.2h.p. R, TX, 2 ton, Economy model
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88 | 44.45 | 95.25 | 22.225 | 3.464567 | 1 3/4 | 3 3/4 | 7/8 |
4 cyl piston set 4674 for Ford - 10h.p.(Short) 1172cc SV Deluxe, C.E. Prefect,
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 65.0875 | 26.19375 | 17.4625 | 2 1/2 | 2 9/16 | 1 1/32 | 11/16 |
1 cyl piston set 5055 for Fiat - 17h.p. 2516cc 518, Ardita 2000, Type O
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82 | 102 | 48 | 24 | 3.228346 | 4.015748 | 1.889764 | 0.944882 |
4 cyl piston set 5639 for Singer - 11h.p. 1459cc Eleven
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.5 | 71.4375 | 38.1 | 15.875 | 2.61811 | 2 13/16 | 1 1/2 | 5/8 |
4 cyl piston set 7058 for Albion - 22.5h.p. HL126, J127, JS127, JL127, KN126, KL126, KS127, KN127, KL127, 70/80/90/100/110cwt, PH, PK114, 115, 24/36 seater passenger, Victor, EN212, EN68A, EN215,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 98.425 | 44.45 | 28.575 | 3 3/4 | 3 7/8 | 1 3/4 | 1 1/8 |
6 cyl piston set 7393 for Morris - 25h.p. Overseas C.R 5.75 to 1, C.I
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82 | 99 | 55 | 22 | 3.228346 | 3.897638 | 2.165354 | 0.866142 |
4 cyl piston set 7557 for Commer - 13.95h.p. 15, 20, 25cwt NI Series A Q15, Q25
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 75 | 93 | 51 | 24 | 2.952756 | 3.661417 | 2.007874 | 0.944882 |
1 cyl piston set 7668 for Rover - 11.9h.p. 1496cc Twelve
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69 | 78.184375 | 40.084375 | 15.875 | 2.716535 | 3 5/64 | 1 37/64 | 5/8 |
4 cyl piston set 7681 for Vauxhall - 10h.p. 1203cc Ten Four, H, C.R. 6.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 75.40625 | 39.6875 | 15.875 | 2 1/2 | 2 31/32 | 1 9/16 | 5/8 |
4 cyl piston set 7695 for Hillman - 9.8h.p. 1185cc Minx, Minx Magnificent, Aero Minx
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 76.99375 | 38.89375 | 16 | 2.480315 | 3 1/32 | 1 17/32 | 0.629921 |
4 cyl piston set 7751 for Standard - 9h.p. 1287cc Teinmouth Big Nine, C.R. 4.9 to 1, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 76.2 | 38.1 | 15.875 | 2 1/2 | 3 8.8817841970013E-16/2 | 1 1/2 | 5/8 |
4 cyl piston set 7771 for Standard - 9.h.p 1052cc, Little 9, 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 60.325 | 69.85 | 34.925 | 15.875 | 2 3/8 | 2 3/4 | 1 3/8 | 5/8 |
4 cyl piston set 7789 for Ford - 10h.p. 10cwt
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 64.29375 | 26.19375 | 17.4625 | 2 1/2 | 2 17/32 | 1 1/32 | 11/16 |
6 cyl piston set 7806 for Vauxhall - 14h.p. 1781cc Light Six ASX
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 75.40625 | 39.6875 | 19.05 | 2.42126 | 2 31/32 | 1 9/16 | 3/4 |
6 cyl piston set 7812 for Morris - 14h.p. 1818cc Series II & III Fouteen Six 'Q'
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 61.5 | 79.5 | 42.5 | 18 | 2.42126 | 3.129921 | 1.673228 | 0.708661 |
6 cyl piston set 7900 for Studebaker - 26h.p. Commander Six, 7A, 8A, 9A, 10A, 11A 12A, Coupe Express K5, L5. Heplex version of Piston 10138
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84.1375 | 94.853125 | 51.990625 | 22.225 | 3 5/16 | 3 47/64 | 2 3/64 | 7/8 |
4 cyl piston set 8027 for Morris - 10h.p. 1140cc Series M, SM Ten Four
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 73.5 | 45 | 16 | 2 1/2 | 2.893701 | 1.771654 | 0.629921 |
4 cyl piston set 8109 for Hillman - 16h.p. 2576cc Sixteen
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 67.5 | 93.5 | 51 | 22 | 2.65748 | 3.681102 | 2.007874 | 0.866142 |
6 cyl piston set 8237 for Austin - 16h.p. Engine fitted to 12-6 chassis 1934-38, 16h.p. 1711cc Fourteen, Goodwood 1937-40, C.R 6.4 to 1, Tornado Marine Engine Model. 6 Cylinder
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 72.23125 | 33.3375 | 14.2875 | 2.57874 | 2 27/32 | 1 5/16 | 9/16 |
1 cyl piston set 8481 for Caterpillar - 2 Cylinder petrol starting engine for Diesel RD6, RD7, RD8 power units, D6100, D6600, D7700, D8800, D11000, D13000
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 107.95 | 61.9125 | 27.78125 | 3 5/8 | 4 1/4 | 2 7/16 | 1 3/32 |
6 cyl piston set 8674 for Lanchester - 13.4h.p. 1527 cc Roadrider, Fourteen, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 59.944 | 69.85 | 31.75 | 15.24 | 2.36 | 2 3/4 | 1 1/4 | 0.6 |
6 cyl piston set 8713 for Morris - 25h.p. Overseas C.R 5.75 to 1, Aluminium, 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82 | 102.5 | 58 | 22 | 3.228346 | 4.035433 | 2.283465 | 0.866142 |
4 cyl piston set 8743 for Ford - 10h.p. 1172cc Prefect, long 4 ring piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 69.85 | 30.95625 | 17.4625 | 2 1/2 | 2 3/4 | 1 7/32 | 11/16 |
4 cyl piston set 8823 for Austin - 10.98h.p, 1237cc MPU Utility, C.R 6.52 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.548 | 69.85 | 31.75 | 14.2875 | 2.62 | 2 3/4 | 1 1/4 | 9/16 |
4 cyl piston set 8892 for Fiat - 10.48h.p. 995cc 508 Balilla 4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65 | 82 | 42 | 18 | 2.559055 | 3.228346 | 1.653543 | 0.708661 |
4 cyl piston set 8999 for Ford - 24h.p. A, AA, B, BB C.R. 4.6 to 1. Aluminium version of cast iron piston 8618
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98.425 | 97.63125 | 48.41875 | 25.4 | 3 7/8 | 3 27/32 | 1 29/32 | 1 |
4 cyl piston set 9035 for Ford - 30h.p. Export V8, 18, 40, 48, 68, C.R 6.12 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.7875 | 75.40625 | 38.89375 | 19.05 | 3 1/16 | 2 31/32 | 1 17/32 | 3/4 |
4 cyl piston set 9211 for Continental - F4162 Industrial F162, LF162, Power Unit PF162, Kerosene
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 21.828125 | 3 7/16 | 3 9/16 | 2 | 55/64 |
6 cyl piston set 9310 for Austin - 28.3h.p. 6 wheeler 4-wheel drive, twin rear axle K3/YF, 4-wheel drive K3/ZD, K5. Aluminium piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 93.6625 | 47.625 | 22.225 | 3 7/16 | 3 11/16 | 1 7/8 | 7/8 |
6 cyl piston set 9745 for Dodge - 27.3h.p. Aluminium version of cast iron piston 5297
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 97.63125 | 50.8 | 21.828125 | 3 3/8 | 3 27/32 | 2 | 55/64 |
1 cyl piston set 9964 for Thornycroft - 30.46h.p. 4.042 litre, Sturdy, YF/TR6, Indirect injection Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.4875 | 111.125 | 60.325 | 31.75 | 3 9/16 | 4 3/8 | 2 3/8 | 1 1/4 |
6 cyl piston set 10083 for Chrysler - 28.35h.p. 4100cc, SV, C34, C38, C45, C48, C51, Royal, Windsor, Newport, 5 tonner, US Army
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 98.425 | 50.8 | 21.828125 | 3 7/16 | 3 7/8 | 2 | 55/64 |
6 cyl piston set 10171 for Bedford - 27.34h.p. 3519cc, series K, M, O, W, 3/4 to 5 Ton, Tractor 6 to 8 Ton, Heplex Piston
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85.725 | 85.725 | 41.275 | 20.6375 | 3 3/8 | 3 3/8 | 1 5/8 | 13/16 |
4 cyl piston set 10491 for Vauxhall - 1939/48 12h.p. 1442 cc Twelve Four, I, CR 6.8 to 1. 1948/52 1 1/2 litre, Wyvern LIX, CR 6.4 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 90.884375 | 55.165625 | 15.875 | 2.73622 | 3 37/64 | 2 11/64 | 5/8 |
6 cyl piston set 10567 for Commer - 26.85h.p. 4086cc SV, LNF5, N5, PN4, PNF4, PNF5, CPNF5, Q2, Q3, Q4, Q5, 2-6 1/2 ton, 24 to 26 seater passenger, Commando, Tractor Trailer 6-10ton
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 85 | 93 | 51 | 24 | 3.346457 | 3.661417 | 2.007874 | 0.944882 |
4 cyl piston set 11121 for Reliant - 747 cc Regent, Prince Regent, regal, 5-12 Cwt Three Wheeler Van. 598 cc Ohv Regal 3/25, 5 Cwt van, CR 7.8 to 1. Up to Engine 88757
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 55.88 | 46.0375 | 22.225 | 12.7 | 2.2 | 1 13/16 | 7/8 | 1/2 |
8 cyl piston set 11376 for Ford - 21.6h.p. 2158 cc SV Vedette, Comete, V8, 2.2 Litre
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.04 | 71.040625 | 36.115625 | 17.4625 | 2.6 | 2 51/64 | 1 27/64 | 11/16 |
4 cyl piston set 11594 for Hillman - 1185 cc SV Minx, MkI, MkII, MkIII
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63 | 73.81875 | 38.89375 | 16 | 2.480315 | 2 29/32 | 1 17/32 | 0.629921 |
1 cyl piston set 11809 for Humber - 29.4 h.p. 4139 cc OHV Super Snipe, Mk IV, Pullman, Imperial
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.9 | 112.9538 | 66.675 | 28.575 | 3 1/2 | 4.447 | 2 5/8 | 1 1/8 |
4 cyl piston set 12377 for Jaguar - 1609 cc 1.5 Litre
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 69.5 | 82 | 45.5 | 19.05 | 2.73622 | 3.228346 | 1.791339 | 3/4 |
4 cyl piston set 12417 for Austin - 8h.p. 900 cc Big Seven/New Eight, C.R. 6.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56.769 | 63.5 | 31.75 | 12.7 | 2.235 | 2 1/2 | 1 1/4 | 1/2 |
4 cyl piston set 12572 for Austin - 18.9h.p. 2660 cc O.H.V. Atlantic A90/Healey Hundred, 2.7 Lit. CR 7.5 to 1-4 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.3125 | 90.4875 | 50.8 | 22.225 | 3 7/16 | 3 9/16 | 2 | 7/8 |
4 cyl piston set 12629 for Morris - 1955-6 1489 cc OHV A50 Cambridge. 1957-61, A50, A55. 1956-62 152 series, Omnivan, Omnitruck, 15 Cwt. Omnicoach, 10 Cwt. Van, J4 10/15 Cwt. Low Comp CR 7.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.025 | 76.99375 | 42.06875 | 17.4625 | 2 7/8 | 3 1/32 | 1 21/32 | 11/16 |
4 cyl piston set 12866 for Austin - 10.65h.p. 1200 cc O.H.V. A40 Cambridge CR 7.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.4685 | 76.99375 | 42.1132 | 17.4625 | 2.5775 | 3 1/32 | 1.658 | 11/16 |
4 cyl piston set 13251 for Ford (American) - 1941-2 4Cyl 1NC/2NC/1ND/2ND/1NY/2NY, 1/2 - 1 Ton. 1939-47 32.5HP (95/100h.p. V8), (09/19/29/59/69/79/99)C, (09/29/69/79/99)D,...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 80.9625 | 45.24375 | 19.05 | 3 3/16 | 3 3/16 | 1 25/32 | 3/4 |
4 cyl piston set 13695 for Continental - F4140, Industrial F140, LF140, Power Unit PF140. Z120 4cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9625 | 90.4875 | 50.8 | 21.828125 | 3 3/16 | 3 9/16 | 2 | 55/64 |
4 cyl piston set 14136 for MG - 1250 cc OHV Midget, 1 1/4 Litre, Series TB, TC, TD, TF, Y, YA, YB
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 66.5 | 73 | 45 | 18 | 2.61811 | 2.874016 | 1.771654 | 0.708661 |
1 cyl piston set 14816 for Austin - 2912 cc OHV A99 Westminster/A110 2.9 litre/ 3 litre Princess. CR 8.3 to 1 6 cyl
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 83.3247 | 87.3125 | 47.625 | 22.225 | 3.2805 | 3 7/16 | 1 7/8 | 7/8 |
1 cyl piston set 15181 for Vauxhall - 2651 cc OHV 2.6 litre, Velox, Cresta
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.55 | 77.978 | 44.45 | 22.0091 | 3 1/4 | 3.07 | 1 3/4 | 0.8665 |
4 cyl piston set 16110 for Fiat - 1295 cc OHV 1300 CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 72 | 88.5 | 45.602 | 22 | 2.834646 | 3.484252 | 1.795354 | 0.866142 |
4 cyl piston set 16201 for MG - 1798 cc OHV MGB1800, CR 8.75 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 76.99375 | 42.06875 | 19.05 | 3.1595 | 3 1/32 | 1 21/32 | 3/4 |
4 cyl piston set 16220 for Singer - 1494 cc OHV Gazelle, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.999 | 82.55 | 46.99 | 22.225 | 3.110197 | 3 1/4 | 1.85 | 7/8 |
4 cyl piston set 16309 for Wolseley - 998 cc OHV Hornet, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 64.5668 | 65.8368 | 34.0868 | 15.875 | 2.542 | 2.592 | 1.342 | 5/8 |
6 cyl piston set 16639 for Vauxhall - 3293 cc OHV Velox, Cresta, Viscount, CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 92.075 | 77.9272 | 44.45 | 21.9964 | 3 5/8 | 3.068 | 1 3/4 | 0.866 |
2 cyl piston set 16993 for Honda - 125 cc OHC Benly C92, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 44 | 53 | 30 | 14 | 1.732283 | 2.086614 | 1.181102 | 0.551181 |
6 cyl piston set 17308 for Ford - 1663 cc OHV Transit 600/850/1100, 101 Engine V4, CR 7.8 to 1. OHV Corsair De Luxe V4 2601E Engine, Industrial V4 CR 9.1 to 1. 6 Cyl 2495 cc OHV Zodiac MkIV...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 101.0158 | 52.0954 | 23.8125 | 3.6869 | 3.977 | 2.051 | 15/16 |
4 cyl piston set 17309 for Ford - 4 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2495...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
Hillman Imp 875cc
Low comp 8.7:1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.2564 | 51.990625 | 26.590625 | 15.875 | 2.766 | 2 3/64 | 1 3/64 | 5/8 |
4 cyl piston set 17490 for Opel - 4 cyl 1492 cc OHC Rekord, Caravan, 1.5 Litre. 6 Cyl 2239 cc OHC Rekord L, Commodore, Coupe, 2200. CR 8.2 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 82.5 | 87 | 45 | 23 | 3.248031 | 3.425197 | 1.771654 | 0.905512 |
4 cyl piston set 17566 for Ford - 1098 cc OHV Escort 1100, 6/8 cwt Van. 2733E Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 17570 for Bedford - 1975 cc OHC CF 22/25/35 cwt. CR 8.5 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 95.25 | 81.8642 | 43.8658 | 25.4 | 3 3/4 | 3.223 | 1.727 | 1 |
4 cyl piston set 18262 for Triumph - 1296 cc OHV 1300 CR 8.5 to 1, Spitfire CR 9 to 1 to Engine RD19476
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73.6473 | 66.9671 | 38.4937 | 20.6375 | 2.8995 | 2.6365 | 1.5155 | 13/16 |
4 cyl piston set 18510 for Triumph - 1991 cc OHV TR2, TR3 Overbored to give 2188 cc, CR 9.24 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87 | 87.427 | 50.8 | 22.225 | 3.425197 | 3.442008 | 2 | 7/8 |
4 cyl piston set 18518 for Austin, Mini, Morris - 1964-5 Mini Cooper S, CR 10 to 1. 1963-4 1071 cc Mini Cooper S CR 11 to 1. 1964-9 1275 cc OHV Mini Cooper S CR 12 to 1. 67 onwards 1275 OHV Marina...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.612 | 58.6105 | 38.0365 | 20.6375 | 2.78 | 2.3075 | 1.4975 | 13/16 |
4 cyl piston set 18679 for Ford - 1098 cc OHV Escort 1100, Export Cortina 1100, 6/8 cwt Van. CR 9 to 1, 2733E Engine
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 18685 for Ford - 1599 cc OHV Cortina 1600, Capri 1600, 2737E Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
1 cyl piston set 18753 for Ford - 1593 cc OHC Cortina 1600 GT, Capri 1600/GT, Cortina 1600 L, Cortina 1600 XL, CR 9.2 to 1.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 87.65 | 73.1 | 41.2 | 24 | 3.450787 | 2.877953 | 1.622047 | 0.944882 |
1 cyl piston set 18943 for Ford - 997 cc OHV Anglia 105E Engine, CR 8.9 to 1. 1198 cc OHV Anglia Super, Cortina 113E Engine, CR 8.7 to 1. 1499 cc OHV Cortina Super, 116E Engine, CR 8.3 to 1. 1499...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.9498 | 64.262 | 38.9636 | 20.6375 | 3.187 | 2.53 | 1.534 | 13/16 |
4 cyl piston set 19105 for Hillman - 875 cc OHC Imp, Super Imp, Husky, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 70.2564 | 52.0573 | 26.67 | 15.875 | 2.766 | 2.0495 | 1.05 | 5/8 |
4 cyl piston set 18647 for Ford - Uprated 711M Engine, Ford Crossflow OHV Kent
1299 cc Original Application:
Ford Capri Mk1 1.3 08/1970-1974
Ford Capri Mk2/Mk3 1.3 1974-1987
Ford Cortina Mk3 1.3...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
6 cyl piston set 19160 for Leyland - 2227 cc OHC 2200 E series/2200HL, CR 9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 74.7776 | 43.1292 | 20.6375 | 3 8.8817841970013E-16/2 | 2.944 | 1.698 | 13/16 |
4 cyl piston set 19256 for Audi - 1871 cc O.H.V. Audi 100 Coupe S/100GL, 1900S Engine. CR 10.2 to 1, SSD
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 84 | 80.5 | 43.6 | 24 | 3.307087 | 3.169291 | 1.716535 | 0.944882 |
1 cyl piston set 19298 for Ford - 7 Cyl 1996 cc OHV Transit 1250/1500/1750, 122 Engine V4, CR 7.8 to 1. OHV Corsair GT, Zephyr 4, MkIV, 2000E, 2602E Engine Industrial V4, CR 8.9 to 1. 6 Cyl 2994...
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.64726 | 94.9198 | 46.0629 | 23.8125 | 3.6869 | 3.737 | 1.8135 | 15/16 |
4 cyl piston set 19470 for Hillman - 1295 cc OHV Avenger 1300, GL, GT, CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 78.6 | 75.7682 | 44.1198 | 23.8125 | 3.094488 | 2.983 | 1.737 | 15/16 |
4 cyl piston set 19659 for Nissan - 988 cc A10 Engine. 79-81; Cherry 1.0 L, GL. 70-76; Cherry 100A Deluxe L. 76-79; Chery F11, GLS. 66-70; Sunny 1000
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 73 | 67.5 | 32.6 | 17.45 | 2.874016 | 2.65748 | 1.283465 | 0.687008 |
1 cyl piston set 19753 for Leyland - 1798 cc OHV 240, 250, Sherpa, CR 6.9 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.2513 | 61.1124 | 42.164 | 20.6375 | 3.1595 | 2.406 | 1.66 | 13/16 |
4 cyl piston set 19985 for Triumph - 1998 cc OHC TR7, CR 9.25 to 1. European Version
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 90.28684 | 70 | 34.1 | 23.8125 | 3.5546 | 2.755906 | 1.34252 | 15/16 |
4 cyl piston set 20161 for Datsun - 1483 cc OHV J15 Engine, Pick Up Ng20, UN620, GN620, CR 8.3 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 77.79 | 79.25 | 39.85 | 21 | 3.062598 | 3.120079 | 1.568898 | 0.826772 |
4 cyl piston set 20264 for Land Rover - 3528 cc Rover V8, Range Rover SD1 Engine, CR 9.35 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 88.8619 | 77.089 | 47.371 | 22.225 | 3.4985 | 3.035 | 1.865 | 7/8 |
1 cyl piston set 20378 for Suzuki - 123 cc 1 Cyl TS125T, K, L, M, A, B, Two Stroke
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 56 | 66.5 | 33.1 | 14 | 2.204724 | 2.61811 | 1.30315 | 0.551181 |
1 cyl piston set 20553 for Ford - 1599 cc OHV Transit 75/90/115, 751M Engine, Low Comp CR 8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80.98536 | 83.82 | 44.2214 | 20.6375 | 3.1884 | 3.3 | 1.741 | 13/16 |
4 cyl piston set 20761 for Ford - 1296 cc CVH Engine OHC Escort 1300 L/GL, Ghia, Estate, CR 9.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 79.99984 | 20.6375 | 3.1496 | 0 | 0 | 13/16 | ||
1 cyl piston set 21145 for Honda - 498 cc XL500, S/SZ/Z/A
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 89 | 65.2 | 29.2 | 21 | 3.503937 | 2.566929 | 1.149606 | 0.826772 |
4 cyl piston set 21776 for Suzuki - 970 cc F10A Engine, OHC Jimny SJ410/Q/V, 4WD, 110S40FK, 1000SJ40VC CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 65.5 | 2.57874 | 0 | 0 | 0 | |||
4 cyl piston set 158809 for Petter - AV1, AVA1, AV2, AVA2, Series II, AH1, Diesel. Water Cooled Bore is 80 mm, Air Cooled is 80.101mm
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 106 | 63.5 | 30 | 3.149606 | 4.173228 | 2 1/2 | 1.181102 |
1 cyl piston set 350026 for Petter - PAZI, Air Cooled, Diesel
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76.2 | 92 | 55.042 | 27 | 3 8.8817841970013E-16/2 | 3.622047 | 2.167008 | 1.062992 |
1 cyl piston set 350185 for Bedford - 8.2 Litre 500 Engine Direct injection Diesel. CR 17 to 1, Al fin design RBP
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 115.8875 | 122.428 | 75.7936 | 44.45 | 4 9/16 | 4.82 | 2.984 | 1 3/4 |
4 cyl piston set 350269 for Leyland - 4 cyl 3.77 Litre Leyland 4/98 Series, 6 cyl 5.65 Litre 6/98, Normally Aspirated, Diesel, CR 16.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 98 | 116.3 | 68.25 | 36.5125 | 3.858268 | 4.57874 | 2.687008 | 1 7/16 |
1 cyl piston set 350384 for Ford - 2496 cc 2.5DI Engine, Diesel Direct Injection Transit, CR 19 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 93.67012 | 94.00032 | 59.48426 | 29.00426 | 3.6878 | 3.7008 | 2.3419 | 1.1419 |
4 cyl piston set 360001 for Fiat - 1116 cc OHC 128, 128 Sport Coupe 1100, L1100, 128 Special 1100, 128 3P 1100, CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 72.3 | 35.3 | 22 | 3.149606 | 2.846457 | 1.389764 | 0.866142 |
4 cyl piston set 583206 for David Brown - 3 cyl 2695 cc 880, 885. 4 cyl 3594 cc 995/996/1200/1210/1212. Direct Injection Diesel. CR 17 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 100.04552 | 105.5624 | 60.3758 | 31.75 | 3.9388 | 4.156 | 2.377 | 1 1/4 |
1 cyl piston set 665872 for Fiat - 125 Berlina, Engine type 125A CR 8.8 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 80 | 83.7 | 44.2 | 22 | 3.149606 | 3.295276 | 1.740157 | 0.866142 |
4 cyl piston set 666708 for Fiat - 1297 cc 131.
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 76 | 78.45 | 38.95 | 22 | 2.992126 | 3.088583 | 1.533465 | 0.866142 |
4 cyl piston set 674110 for Simca - 1290 cc OHV Aronde, Rush Engine, CR 7.5 to 1. Rush Super engine CR 8.5 to 1. 1300, 1301 CR 8.3 to 1. 1301GL, 1301LS CR 8.6 to 1
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 74 | 78.5 | 42 | 22 | 2.913386 | 3.090551 | 1.653543 | 0.866142 |
4 cyl piston set 11920 JP for Ford - 10h.p. 1172 cc SV Taunas 12M, Anglia, Prefect, Escort, Squire, 1600 Series
| Metric (mm) | English (Inches) | ||||||
|---|---|---|---|---|---|---|---|
| Bore | Piston Height | Compression Height | Gudgeon Pin Dia. | Bore | Piston Height | Compression Height | Gudgeon Pin Dia. |
| 63.5 | 74.678 | 45.34 | 17.4625 | 2 1/2 | 2.940079 | 1.785039 | 11/16 |
